Rush Render Queue - Command Line Options V 103.07 05/28/15 (C) Copyright 2008, 2015 Seriss Corporation. All rights reserved. (C) Copyright 1995,2000 Greg Ercolano. All rights reserved. Strikeout text indicates phased out or obsolete operators. Text in red indicates new features; hovering over the text shows the version number.

rush -acct_archive

rush -acct_archive [-dbasedir /path] Rush Accounting Data Archival Lets you write scripts that take monolithic Rush cpu.acct files (from all versions of Rush) and write them to a file server directory, breaking the data out into a year/month/day directory tree by hostname. This data can then be loaded by the Rush python modules, e.g. RushAcct.py, etc. In Rush 103.00, you can use the new rush.conf file command cpuacct.dbasedir to tell rush to automatically archive cpu accounting data to the file server year/month/day directory tree. This new '-acct_archive' flag is provided just to take old monolithic files and commit them to this new ascii based directory layout. If -dbasedir is specified, the pathname argument should point to a file server directory where the data will be broken out into year/month/day subdirectories (which are created automatically). If -dbasedir is *not* specified, the default path set in the rush.conf file for cpuacct.dbasedir will be used. -acct_archive Examples rush -catlog cpu.acct +any -t 5 > alldata.acct rush -acct_archive -dbasedir /yourserver/rush-acct-dbase < alldata.acct Take all the cpu.acct files from all the rush machines and combine them all into a single temp file, then archive the data to the directory tree at /yourserver/rush-acct-dbase/ rush -acct_archive -dbasedir /yourserver/rush-acct-dbase < /usr/local/rush/var/cpu.acct Take the single cpu.acct data from /usr/local/rush/var/cpu.acct and write it to the server directory tree at /yourserver/rush-acct-dbase/ See Also cpuaccct.dbasedir -- Where to archive Rush accounting data

rush -ac

rush -ac <cpuspec..> [jobid..] Add Cpus. Adds cpus to the running job. Examples: Add Cpu Examples rush -ac tahoe@300 Add one cpu on tahoe at 300 priority rush -ac tahoe=2@300 +farm=10@100k Add two cpus on tahoe, 10 cpus for +farm hostgroup rush -ac +any=10@30 Add any 10 available cpus at priority 30 For more details on the different syntax of cpu specifications, see the Cpus submit command. See Also Cpus -- Submit command to add cpus to a job rush -rc' -- Command line flag to remove cpus

rush -af

rush -af <framerange..> [jobid..] Add Frames. Adds frames to the current framelist. Adding frames that already exist yields an error. Example: Add Frames Examples rush -af 10-20 Add 10 thru 20 to the current job rush -af 1 5 10-100 800-899 Add frames 1, 5, 10 through 100 and 800 through 899 to the current job rush -af -10--5 Add negative frames: -10 thru -5 rush -af .1-5,.1 Add floating point frames .1 through 5 stepping by .1 (.1, .2, .3 .. 4.9, 5.0) rush -af 20-25=Hold Add 20 thru 25 in Hold state rush -af 30-35:"To be done" Add 30 thru 35, Notes "To be done" rush -af 40-45=Done:"To be done" Add 40 thru 45 as Done with Notes See Also Frames -- Submit command to add frames to a job

rush -an

rush -an <hostname|+hostgroup..> [jobid..] Add Nevercpus. Prevents the job from rendering on the specified hosts. Example: Add Never Cpus Examples rush -an tahoe +farm   Add host tahoe and all hosts in hostgroup   +farm as machines to never use. See Also Nevercpus -- Submit command to add 'never cpus' to a job

rush -args

rush -args  Read rush arguments from stdin. (103.00 and up) This allows you to make one invocation of rush, and send a stream of command line arguments on stdin, one set of rush commands per line. This is an optimization to allow execution of many rush commands without the overhead of rush reloading the rush.conf and hosts files for each operation. (At some facilities, the hosts file can be so large as to incur latency for each command executed). For instance, the following 3 commands: rush -cp -fu linux001.23 .922742 .922743 .922744 .922745 @1 rush -cp -fu linux001.24 .923061 .923062 .923064 @1 rush -cp -fu linux001.28 .925878 .925879 .925880 @1 ..can be equivalently executed from a shell script as: rush -args << EOF -cp -fu linux001.23 .922742 .922743 .922744 .922745 @1 -cp -fu linux001.24 .923061 .923062 .923064 @1 -cp -fu linux001.28 .925878 .925879 .925880 @1 EOF ..such that only one instance of rush is started (thus only loading the rush hosts and rush.conf files once), and all three "-cp" commands are executed one after the other. This can be useful with scripts that want to run several rush commands in succession through a pipe. For instance, a python example: Example use of 'rush -args in Python' #!/usr/bin/python import subprocess pipe = subprocess.Popen("rush -args", shell=True, stdin=subprocess.PIPE).stdin    print >>pipe, "-lj"; # List Jobs print >>pipe, "-lf tahoe.1"; # List Frames print >>pipe, "-lfi tahoe.1"; # List Frame Info print >>pipe, "-lc tahoe.1"; # List Cpus pipe.close() Whitespace and Comments Leading white space, blank lines, and lines starting with '#' are ignored. This allows arguments and comments to be indented, and blank lines to be used for programming clarity. Example: Example use of 'rush -args' rush -args << EOF # DUMP STALE JOBS -dump -fu eagle.37 eagle.38 eagle.39 eagle.50 eagle.58    -dump -fu tahoe.3 tahoe.9 tahoe.10 # OFFLINE WORKSTATIONS -offline +work +previz # PING THE TAPE BACKUP SERVERS -ping shasta tahoe bluestone -t 3 EOF Error Handling If any of the commands returns a non-zero exit code, "ARGS_ERROR" messages of the following format indicate the line number and exit code of the failed command returned, and the final exit code of 'rush -args' will be 1. This allows your program to see which line failed, what the actual exit code of that line was. This error message format is guaranteed not to change, so as to be parsable by your own program. The format of these errors follows the existing standard for rush error messages to start with 'rush:', in this case "rush: ARGS_ERROR" uniquely identifies '-args' specific exit code messages, e.g.: rush: ARGS_ERROR at line <<LINE#>> of <<FILENAME>>, exitcode <<EXITCODE>>: <<LINE_CONTENTS>> So a literal example stderr for a failed command due to a bad hostname might be: rush: 'tahoo' unknown host <-- Output from the failed command rush: ARGS_ERROR at line 10 of stdin, exitcode 1: -getoff tahoo <-- parsable error message from 'rush -args' showing exit code Quoting The commands you specify are NOT parsed by a shell. So shell specific characters like: <,|,>,&,$,% ..are not treated specially. The only characters that are treated specially are (") and (\): (") can be used to protect arguments that contain spaces (\) can be used to protect quotes (\\) can be used to protect the backslash So for instance: Example use of 'rush -args' #!/bin/sh rush -args << EOF -online emporia zoar eagle bluestone -msg "New drives installed" -getoff tahoe superior huron ontario -msg "Down for repairs" -command "python //path/to/my_script.py -arg1 -arg2 -arg3" tahoe.34    -command "cmd /c del c:\\temp\\myfile.txt" tahoe.34 EOF ..shows how to protected spaces in -online/offline's '-msg' flag, and in -command's arguments, the last example showing how to double-up backslashes to specify pathnames containing backslashes. Caveats When -args is specified, you can specify *any* of the rush command line arguments EXCEPT -args. This prevents recursion and a confusion of multiple inputs. Lines passed on stdin to -args can optionally have the 'rush' commands included. This way a list of rush commands can be copy/pasted directly into -args, without having to delete all the 'rush' commands. For instance, the following do the same thing: Example use of 'rush -args' # WITH 'rush' SPECIFIED rush -args << EOF rush -getoff tahoe superior rush -dump tahoe.34 tahoe.35     EOF # WITHOUT 'rush' SPECIFIED rush -args << EOF -getoff tahoe superior -dump tahoe.34 tahoe.35     EOF

rush -autodump

rush -autodump <off|done|fail|donefail> [jobid..] Automatic Dump. Configures job to automatically dump when there are no more frames to render. Autodump Examples autodump off Don't autodump; job remains when frames are DONE (default) autodump done Job dumps itself when all frames are DONE autodump fail Job dumps itself if job finishes with any FAIL frames autodump donefail Job dumps itself if all frames are DONE or FAIL See Also AutoDump -- Submit command to set the autodump behavior for the job

rush -catlog

rush -catlog [-foe] <file> [file..] [host..] cat(1) one of the daemon's logs. View one of the various local [remote] daemon logs; access both new and old versions of rushd.log, cpu.acct, etc. 'file' can be any one of: Catlog File Options rushd.log View today's daemon log Orushd.log View yesterday's daemon log (O='Old') cpu.acct View current rush accounting log Ocpu.acct View last rotated (O='Old') accounting log mail.log View the mail.log (if enabled via smtp.debug) [-foe] "Fail On Error". Causes the command to stop on any hostname lookup errors (such as temporary DNS or LDAP issues), instead of just printing warnings and continuing to run to handle any other hostnames specified. (default: off) *This flag new in 103.07* What follows are some examples of using 'rush -catlog'.. Catlog Examples rush -catlog rushd.log View the local rushd.log file rush -catlog rushd.log geneva View geneva's daemon log rush -catlog Orushd.log geneva View yesterday's daemon log from host 'geneva' rush -catlog cpu.acct View the local accounting log rush -catlog cpu.acct +any | cpu-utilization.pl -asciigraph Generate a cpu utilization report from all host's accounting logs Caveat: This command makes the older '-dcatlog' command redundant.

rush -checkconf

rush -checkconf [filename|-] Check for errors in specified rush.conf file.. (Administrative) Checks a rush/etc/rush.conf file for errors. Returns an exit code indicating success or failure; 0=ok, 1=error(s) found. If filename is unspecified, $RUSH_DIR/etc/rush.conf is checked. If filename is '-', contents to be checked is read from stdin. NOTE: In Rush 102.42a9c and older: <filename|-> was REQUIRED. Example: Example CSH Script Using 'rush -checkconf' #!/bin/csh -f ### ### Script to edit the rush.conf file, and rdist it out ### set TMPFILE=/usr/tmp/rush.conf.$$ cp /usr/local/rush/etc/rush.conf $TMPFILE # work on a COPY, in case user really messes it up vi $TMPFILE rush -checkconf $TMPFILE if ( $? ) then echo Config file has errors set err=1 else foreach i ( tahoe superior erie ) echo --- $i rdist -c $TMPFILE ${i}:/usr/local/rush/etc/rush.conf end set err=0 endif rm -f $TMPFILE exit $err To use rsync(1), try replacing 'rdist -c' with 'rsync -avz' in the above example.

rush -checkhosts

rush -checkhosts <filename|-> Checks for errors in the specified rush/etc/hosts file. (Administrative) Checks a rush/etc/hosts file for errors. Returns an exit code indicating success or failure; 0=ok, 1=error(s) found. If filename is unspecified, $RUSH_DIR/etc/hosts is checked. If filename is '-', contents to be checked is read from stdin. NOTE: In Rush 102.42a8 and older: <filename|-> was REQUIRED. Example: Example CSH Script Using 'rush -checkhosts' #!/bin/csh -f ### ### Script to edit the rush/hosts file, and rdist it out ### set TMPFILE=/usr/tmp/rush-hosts.$$ cp /usr/local/rush/etc/hosts $TMPFILE # work on a COPY, in case user really messes it up vi $TMPFILE rush -checkhosts $TMPFILE if ( $? ) then echo Rush hosts file has errors set err=1 else foreach i ( tahoe superior erie ) echo --- $i rdist -c $TMPFILE ${i}:/usr/local/rush/etc/hosts end set err=0 endif rm -f $TMPFILE exit $err To use rsync(1), try replacing 'rdist -c' with 'rsync -avz' in the above example.

rush -command

rush -command 'cmd [args..]' [jobid..] rush -command [jobid..] < file Set Render Command. Changes the command that is executed every frame, normally set in your Submit Script by the Command. Example: If 'cmd [args]' are not supplied, the command will be read from stdin. This is useful to avoid shell quoting issues. If multiple lines are specified, they will be joined into one single line. Command Examples rush -command '/bin/sleep 30' Set command to sleep 30 seconds per frame rush -command < file Set command to contents of 'file' on stdin rush -command '/job/run/myrender' tahoe.21 tahoe.22 Change command for two jobs Note that a full path to the command is normally required. Spaces are used to separate arguments, but the entire command and arguments must be quoted. The command is usually a simple Render Script. Here are some example 3rd Party Render Scripts. See Also Command -- Submit command to set the job's render command rush -commandflags -- Sets flags that affect how the render command is executed

rush -commandflags

rush -commandflags option[,option] [jobid..] Set Command Flags. (New in 103.00) Sets optional flags that affect how the render command is executed. The specified flags are logically 'OR'ed to augment existing flags. So if the current flags are 'quote,escape', and you then run 'rush -commandflags useshell,quote', the result will leave 'quote,escape,useshell' enabled. If you want to set ONLY the flags you specify, precede your list of flags with 'off' to zero out any existing flags first. Then your flag specifications will be appended to that. (Note: flags are parsed left-to-right, so you want 'off' to be first in the list). So if the current flags are 'quote,escape', and you run 'rush -commandflags off,quote,useshell', the result will leave only 'quote,useshell' enabled. The following options are supported, which can be separated by commas to specify several at a time: -commandflags Options quote Honor double quotes in the command. This can be used to protect spaces in command arguments. escape Honor escape characters (\) in the command. Use this to escape certain characters (like '$' and '"'). Use this to protect quotes-within-quotes (if 'quote' is specified) and to protect '$' (if 'expandvars' is specified) expandvars Expand environment variables in the command. before it's executed. Variables can be specified in the format ${VARNAME} across both platforms. useshell Run the command in a native shell. Under windows this means a DOS "cmd" shell. Under unix this means a Bourne /bin/sh. off Disable all command flags. Use this at the beginning of your list of flags

rush -cont

rush -cont [jobid..] rush -cont - Continue a Paused Job. Continues a job that was paused with rush -pause. If '-' is specified, jobids are read from stdin. (Useful if the list of jobids exceeds operating system limits for argument lists and environment variable sizes) Pausing a job no longer cancels 'Waitfor'; it was decided in 102.40h that the older behavior of having 'rush -cont' cancel 'WaitFor' was a bug, not a feature. The proper way to cancel WaitFor to get a job running is to use 'rush -waitfor -'. See Also WaitFor -- Submit command to defined other jobs to 'wait for'

rush -cp

rush -cp [jobid..] <.JobTid [..]> <@[+-]pri['kar']> rush -cp [jobid..] <cpuspec [..]> <=#cpus> Change Priority. Changes priority for the cpus specified. The cpus to be changed can either be specified as 'cpuspec' (eg. "+any=10@100", or '*' for ALL cpus in the job), or by individual 'JobTid' values to change specific host values. JobTid values ("Job Task IDs") can be found in the 'rush -lc' report. Examples: rush -cp examples rush -cp +any=50@100 @200 Change the priority from 100 to 200 rush -cp +any=50@100 @+10 Increase the priority by 10 (from 100 to 110) rush -cp "*" @+10 Increase the priority of ALL cpus in the job by 10. rush -cp +any=50@100 =40 Change the cpu cap from 50 down to 40 rush -cp +any=50@100 =40@200 Change the cpu cap from 50 down to 40, and the priority up from 100 to 200 Changing Priority of Cpus Priorities can be changed while cpus are busy. If a busy cpu's priority is changed, the busy task(s) inherit the new priority, which is used for all subsequent scheduling and priority battles. You can speicify a new priority as a fixed, e.g. "@100" to change the priority to "100". Or you can offset the existing priority by a +/- value, e.g. '@+5' to raise the priority by 5, '@-5' to lower the priority by 5. When raising or lowering priority with offsets, the resulting value is silently clamped within the range specified with the rush.conf file's priority.range. Examples: Example of Changing Cpu Priorities % rush -lc CPUSPEC[HOST] STATE FRM PID JOBTID PRI ELAPSED +any=10@100[vaio] Busy 0007 1030 131 100 00:01:45 +any=10@100[vaio] Busy 0008 1031 132 100 00:01:45 +any=10@100[tahoe] Busy 0004 19829 133 100 00:00:05 +any=10@100[tahoe] Busy 0005 19831 134 100 00:00:05 % rush -cp '*' @+5 vaio.21 +any=10@105: priority was +any=10@100, now +any=10@105 PRIORITY HAS NOW BEEN INCREASED BY 5 FOR ALL CPUS IN THE JOB vaio.21 % rush -lc CPUSPEC[HOST] STATE FRM PID JOBTID PRI ELAPSED +any=10@105[vaio] Busy 0007 1030 131 105 00:02:03 +any=10@105[vaio] Busy 0008 1031 132 105 00:02:03 +any=10@105[tahoe] Busy 0004 19829 133 105 00:00:28 +any=10@105[tahoe] Busy 0005 19831 134 105 00:00:28 % rush -cp '*' @-5 vaio.21 +any=10@100: priority was +any=10@105, now +any=10@100 PRIORITY HAS NOW BEEN DECREASED BY 5 FOR ALL CPUS IN THE JOB vaio.21 % rush -lc CPUSPEC[HOST] STATE FRM PID JOBTID PRI ELAPSED +any=10@100[vaio] Busy 0007 1030 131 100 00:02:14 +any=10@100[vaio] Busy 0008 1031 132 100 00:02:14 +any=10@100[tahoe] Busy 0004 19829 133 100 00:00:39 +any=10@100[tahoe] Busy 0005 19831 134 100 00:00:39 % rush -cp .131 .132 @350k vaio.21 +any=10@100: priority was 100, now 350k vaio.21 +any=10@100: priority was 100, now 350k PRIORITY FOR TWO CPUS IN vaio.21 (SPECIFIED BY JOBTID'S) HAVE BEEN SET TO 350k % rush -lc CPUSPEC[HOST] STATE FRM PID JOBTID PRI ELAPSED +any=10@100[vaio] Busy 0007 1030 131 350k 00:02:25 +any=10@100[vaio] Busy 0008 1031 132 350k 00:02:25 +any=10@100[tahoe] Busy 0004 19829 133 100 00:00:40 +any=10@100[tahoe] Busy 0005 19831 134 100 00:00:40 Caveats: The CPUSPEC column will not reflect the priority change if single <.jobtid> values are modified, only the effective priority (shown in the PRI column) will show the new value. The only time the CPUSPEC will reflect a priority change is the entire cpuspec is being changed (<cpuspec>='+any=10@100') or if ALL cpus in the job are being changed (<cpuspec>='*') GUIs (like IRUSH) make best use of this option, since they hide the mundane task of visually finding JOBTIDs from the -lc report, and transcribing them with dot prefixes for the -lc command. Changing Cpu Limits For Cpus 'rush -cp' can be used to change the number of cpus in a cpuspec. For instance, 'rush -cp +any=50@100 =40' will change '+any=50@100' to '+any=40@100' without killing any running frames. Example: Example of Changing Cpu Limits % setenv RUSH_JOBID vaio.36 % rush -lc CPUSPEC[HOST] STATE FRM PID JOBTID PRI ELAPSED NOTES +any=10@500[tahoe] Busy 0012 11443 343 500 00:00:10 +any=10@500[tahoe] Busy 0013 11445 344 500 00:00:10 +any=10@500[nt-1] Busy 0008 293 345 500 00:00:11 +any=10@500[nt-1] Busy 0009 246 346 500 00:00:11 +any=10@500[vaio] Busy 0015 11489 347 500 00:00:07 +any=10@500[vaio] Busy 0014 11484 348 500 00:00:09 +any=10@500[imac] Busy 0011 22530 351 500 00:00:11 +any=10@500[imac] Busy 0010 22528 352 500 00:00:11 % rush -cp +any=10@500 =3@500 vaio.36 +any=3@500: priority was +any=10@500, now +any=3@500 NOW SET TO 3 CPUS, BUT RENDERS STILL RUNNING, NOTHING IS KILLED.. % rush -lc CPUSPEC[HOST] STATE FRM PID JOBTID PRI ELAPSED NOTES +any=3@500[tahoe] Busy 0021 11453 343 500 00:00:41 +any=3@500[tahoe] Busy 0020 11451 344 500 00:00:41 +any=3@500[nt-1] Busy 0016 280 345 500 00:00:43 +any=3@500[nt-1] Busy 0017 71 346 500 00:00:43 +any=3@500[vaio] Busy 0022 11499 347 500 00:00:39 +any=3@500[vaio] Busy 0023 11501 348 500 00:00:39 +any=3@500[imac] Busy 0018 22534 351 500 00:00:42 +any=3@500[imac] Busy 0019 22536 352 500 00:00:42 TIME PASSES, RENDERS START FINISHING, 3 CPU LIMIT TAKES EFFECT % rush -lc CPUSPEC[HOST] STATE FRM PID JOBTID PRI ELAPSED NOTES +any=3@500[tahoe] Busy 0026 11459 343 500 00:00:04 +any=3@500[tahoe] JobPass - - 344 500 00:01:01 Cpu max (3/3 busy) +any=3@500[nt-1] Idle - - 345 500 00:01:01 Cpu max (4/3 busy) +any=3@500[nt-1] Idle - - 346 500 00:01:01 Cpu max (4/3 busy) +any=3@500[vaio] JobPass - - 347 500 00:01:01 Cpu max (3/3 busy) +any=3@500[vaio] JobPass - - 348 500 00:01:01 Cpu max (3/3 busy) +any=3@500[imac] Busy 0024 22540 351 500 00:00:07 +any=3@500[imac] Busy 0025 22542 352 500 00:00:05 See Also Cpus -- Submit command has details on the syntax of cpu specifications rush -rc' -- Command line flag to remove cpus from an existing job

rush -criteria

rush -criteria 'criteria strings' [jobid..] Job Criteria. Sets the criteria string for the job. Use '-' to specify no criteria. See Also Criteria -- Submit command to set host criteria

rush -d

rush -d [flags..] Rush client side debugging. Enables debugging messages in the 'rush' client program only. (This does not affect the daemon). Supports the same flags as the -dlog option; see the table of logging flags for the complete list of supported flags. Examples: 'rush -d [flags]' Examples rush -lf -d t Enable TCP debug messages (t) for the '-lf' command. rush -laj -d u Enable UDP debugging messages (u) for the '-laj' command. rush -lf -d a Enable ALL debugging messages (a) for the '-lf' command. See Also rush -dlog' -- full description of all the [flags]

rush -dcatlog

rush -dcatlog [host..] NOTE: This option is deprecated, in favor of rush -catlog Daemon cat(1) Log File. View the rushd.log daemon on the local [remote] host. rush -dcatlog prints the current rushd.log (usually today's) rush -dcatoldlog prints the last rotated log (usually yesterday's). Caveat: for reasons strange and unusual, all daemon 'catlog' output has a '>' prepended to each line.

rush -deltaskfu

rush -deltaskfu <jobid> <JobTid> rush -deltaskfu <jobid> <CpuTid> cpuserver Delete Task, Force Unconditionally (Administrative) Users should not use this command. Use 'rush -rc' to remove cpus from your job. Deletes individual 'tasks' from a job server or cpu server. Only root and the rush adminuser can use this command. This command has two forms; in one case it takes two arguments; a jobid and JobTid, to forcibly remove a task from a job's list of cpu reservations. The second form it takes 3 arguments; a jobid, a CpuTid, and a hostname of a cpu server, forcibly removing that task from the cpu server's tasklist (i.e. 'rush -tasklist <hostname>'). Examples: Delete Task Examples rush -deltaskfu vaio.55 117 Delete JOBTID #117 from job vaio.55 rush -deltaskfu vaio.55 183 tahoe    Delete CPUTID #183 (from 'rush -tasklist') from host tahoe for jobid vaio.55 JOBTID values can be found in -lc, -lcf and -tasklistfull reports. CPUTID values can be found in -lcf and -tasklistfull reports. Caveat: This command is not intended for casual use. It is to be used by administrators in unusual situations where cpus are stuck due to communications problems between machines. Use this command carefully. Users should really use 'rush -down' instead, which is the best way to tell Rush a remote machine is 'down' (or not responding).

rush -dependon

rush -dependon [-|depjobid[,..]] Set Dependency On Other Jobs. Sets new 'dependon' jobids for the current [specific] job. See the submit script docs on DependOn for more info. Read the examples carefully, to avoid confusing jobid(s) to affect with new jobids for the dependon command; remember to separate all 'dependon' jobids with commas instead of spaces. Caveats: Setting 'dependon' to a new value disables all previous values (i.e., clears them first). Setting dependon to '-' will disable it, but you will have to un-Hold any frames manually. All 'dependon' jobids must have the same hostname as the job being modified. See also, rush -waitfor. To differentiate between the new value for 'dependon', and the jobid(s) to be affected, the new value for 'dependon' must be a comma-separated list of jobids with no spaces. Examples: Examples of using 'rush -dependon' rush -dependon - Disable all dependencies rush -dependon tahoe.37,tahoe.38, Job now depends on 'tahoe.37' and 'tahoe.38'. Trailing comma required rush tahoe.40 -dependon tahoe.37,tahoe.38, tahoe.40 now depends on 'tahoe.37' and 'tahoe.38' rush tahoe.40 -dependon tahoe.37, tahoe.40 now depends on job 'tahoe.37' Trailing comma on tahoe.37 is required See Also -dependonstate -- Rush command line flag to change the job's DependOn frame state DependOn -- Submit command to defined jobs this job should 'depend on' DependOnState -- Submit command to set the DependOn frame states

rush -dexit

rush -dexit [-foe] [remotehost..] Daemon Exit. (Administrative) Tells a daemon to exit immediately via TCP. Acknowledges success. Only root and the rush adminuser can use this command. Automatically saves job checkpoint before exiting. [-foe] "Fail On Error". Causes the command to stop on any hostname lookup errors (such as temporary DNS or LDAP issues), instead of just printing warnings and continuing to run to handle any other hostnames specified. (default: off) *This flag new in 103.07*

rush -dexitnow

rush -dexitnow [-foe] [remotehost..] Daemon Exit Now. (Administrative) Tells daemon to exit immediately, via UDP. There is no acknowledge. Only root and the rush adminuser can use this command. Use only in case of emergency. Automatically saves job checkpoint before exiting. [-foe] "Fail On Error". Causes the command to stop on any hostname lookup errors (such as temporary DNS or LDAP issues), instead of just printing warnings and continuing to run to handle any other hostnames specified. (default: off) *This flag new in 103.07*

rush -dlog

rush -dlog <flags> [remotehost..] Daemon Debug Logging (Administrative) Enables certain daemon debug logging flags. Only root and the rush adminuser can use this command. Use 'rush -dlog -' to disable all debugging. Logging Flags These are flags that can be used with: 'rush -dlog' to enable daemon debugging messages in the rushd.log, eg: 'rush -dlog utE' 'rush -d' to enable client side debugging messages to the user's screen, eg: 'rush -d t -lfi' In the rush.conf file's LogFlags These flags can be combined to accumulate logging verbosity. All flags can be enabled by specifying 'a', e.g. 'rush -dlog a'. All flags can be disabled by specifying '-', e.g. 'rush -dlog -' - - A single dash is used to disables all debugging flags a - all b - bump mechanism logging c - select() info d - log duplicate/redundant receipt of packet drops e - events (time oriented, async, lic unpause) f - fork/wait g - taskcleanup related (103.00+) h - hostname lookups j - Log job submissions and job state changes k - Log bumped/killed/usurped tasks l - Logical string evaluations m - memory calculations (RAM) during priority battles, etc n - network commands (udp/tcp) o - connect()/open()/close()/bind()/socket() (low level) p - parse command line arguments, submit scripts q - sequence id errors are printed (default:off) r - reboot management/transactions, and checkpoint purges of old tasks s - signals t - tcp u - udp w - 'waitfor' and 'dependon' checks x - show negative cache events y - yp lookups B - debugging for BadJobid transmissions C - class ToWords/FromWords (PROBABLY OBSOLETE) D - dumpsig debugging (Bluesky: 1.21) F - File loading line-by-line debugging E - Errors not normally displayed (benign, but suspect) J - Job Objects (win2k job objects kill mechanism msgs) K - Actual kill commands executed L - Locks on files M - Microsoft specific debugging N - Newtask and notify advertising O - (The letter 'O', NOT zero) program loops P - server: Priority mechanism, client: log 'rush -push' mechanism Q - monitor timeouts R - Reaper msgs S - Server/Client context switches T - task/taskack transactions U - update (scheduling, priority mechanism, idle cpu management) V - ram choking info (expandcpus_ramchoke) W - 'Wakeup' pass states; pass->unpass state changes X - Random UDP message dropping -- TESTING ONLY!! ('a' does not affect this option, it must be specified explicitly) Z - reserved for on the fly debugging problems 0 - (ZERO) jobcheckpoint snapshot messages @ - PROTOCOL TEST FOR TASK_TIMEOUT -- TESTING ONLY!! Induces 60 second sleep before sending TASK_START. ('a' does not affect this option, it must be specified explicitly) + - Disables cpu intensive bump checks % - Debug Start state problem (timeouts, task state changes) ^ - Update choke messages Examples: Examples: Enabling And Disabling Rushd 'Debug Logging' rush -dlog ut tahoe      Enable UDP (u) and TCP (t) debugging for daemon on host tahoe rush -dlog - tahoe Disable all debugging flags for the daemon on host tahoe

rush -dlogstats

rush -dlogstats [host|+hostgroup..] Daemon Log Statistics (Administrative) Useful for easily determining problems with machines on large networks. Checks the local [remote] daemon log for particular kinds of errors, and logs the number of times each error appears in a table summary. Check Daemon's Log File Statistics % rush -dlogstats +any # ************ Problems ************* **Security* ************* Normal ************** # SID Hostname Alert Fail Error Warn Exit Fork Bump Secur Start Rot Info JobSt JobEn JobKi l 0 geneva 2 0 0 0 0 0 0 0 0 1 0 0 0 0 l 0 rotwang 0 0 0 0 1 0 0 1 1 1 2 0 0 0 l 0 ontario 0 0 0 0 0 0 0 0 1 1 2 1 0 0 This report shows that geneva has two 'ALERT' errors in its daemon log, which might indicate a problem worth investigating with 'rush -catlog rushd.log geneva | grep ALERT'. Debug Log Statistics: Field Descriptions Alert Possible system problem; a systems operation unexpectedly failed. For instance, daemon can't bind() to port, because some other entity is holding the port open. Or a select() that should either timeout or return data, actually failed. Or, a tcp/udp command was malformed. Fail Normal operations, failure condition detected and handled. Error An error condition (usually enabled via 'rush -dlog E') Warn Warn of a non-error condition (ie. use of obsolete ops) Exit Error so fatal, it caused daemon to exit. Fork Unable to fork a new process. Bump A job was bumped (killed) during eg. a priority battle. Secur(e) Attention to sysadmins: someone is trying to circumvent the permissions. eg. someone is changing a job they don't own with '-fu'. Start Daemon was started. Rot(ate) rushd.log was rotated. Info Normal operations information worthy of note. JobSt(art) A job was started. JobEn(d) A job ended. JobKi(ll) A job was dumped.

rush -drivemaps

rush -drivemaps Drive Mappings Report. Lists any drive mappings configured in the rush/etc/path_convert file. The output of this command can be used by scripts to determine which drive mappings should be in place. 'rush -drivemaps' Example % rush -drivemaps x //server/prod1 y //server/prod2 z //server/prod3 % grep drive_map /usr/local/rush/etc/path_convert os=all drive_map "x:" "//server/prod1" os=all drive_map "y:" "//server/prod2" os=all drive_map "z:" "//server/prod3" %

rush -dstats

rush -dstats [-z] host Daemon Statistics. (Internal use). Show the daemon's internal statistics. Used mainly for debugging. If -z is specified, it zeroes out the statistics. 'rush -dstats' Example % rush -dstats tahoe Host: tahoe JixHits(Misses): 485 (0) # number of successful job index lookups, value in parens indicates number of misses. CixHits(Misses): 491 (0) # number of successful cpu index lookups, value in parens indicates number of misses. TixHits(Misses): 491 (0) # number of successful task index lookups, value in parens indicates number of misses. FixHits(Misses): 286 (0) # number of successful frame index lookups, value in parens indicates number of misses. SchedulerElapsed[0]: 05/18,10:37:42 -- scheduler took 0 secs, _Update() ran 1 loops, AdvertiseIdle took 0 passes # Info about the SchedulerElapsed[1]: 05/18,10:37:34 -- scheduler took 0 secs, _Update() ran 1 loops, AdvertiseIdle took 0 passes # last 10 runs SchedulerElapsed[2]: 05/18,10:37:26 -- scheduler took 0 secs, _Update() ran 1 loops, AdvertiseIdle took 0 passes # of the scheduler SchedulerElapsed[3]: 05/18,10:37:18 -- scheduler took 0 secs, _Update() ran 1 loops, AdvertiseIdle took 0 passes SchedulerElapsed[4]: 05/18,10:37:10 -- scheduler took 0 secs, _Update() ran 1 loops, AdvertiseIdle took 0 passes SchedulerElapsed[5]: 05/18,10:37:02 -- scheduler took 0 secs, _Update() ran 1 loops, AdvertiseIdle took 0 passes SchedulerElapsed[6]: 05/18,10:36:54 -- scheduler took 0 secs, _Update() ran 1 loops, AdvertiseIdle took 0 passes SchedulerElapsed[7]: 05/18,10:36:46 -- scheduler took 0 secs, _Update() ran 1 loops, AdvertiseIdle took 0 passes SchedulerElapsed[8]: 05/18,10:36:38 -- scheduler took 0 secs, _Update() ran 1 loops, AdvertiseIdle took 0 passes SchedulerElapsed[9]: 05/18,10:36:30 -- scheduler took 0 secs, _Update() ran 1 loops, AdvertiseIdle took 0 passes Jobs: 62 # How many jobs are being served by this machine Procs: 0 # How large the G_procs[] array is Tasks: 0 # How many tasks are in this cpuserver's tasklist LogFlags: - # Current -dlog flags enabled for the daemon NextFD: 7 # The next unused file descriptor (useful for detecting unclosed files) SecsSinceBoot: 425002 # How long the daemon has been running UdpTransactors: 0 (ttl=10) # UDP packet assembly debugging info

rush -done

rush -done <framerange|framestate..> [jobid..] Done Frames. Changes frame(s) into the Done state for current [specific] job. If frames are running, they are killed and enter the 'Done' state on completion. The frames to affect can either be specified as a frame range (i.e., 1-100) or as a frame state, for which all matching frames will be affected. Examples: 'rush -done' Examples % rush -done 1-100 'Done' frames 1 through 100 % rush -done fail 'Done' all frames currently Fail % rush -done fail que    'Done' all frames currently Fail or Que   % rush -done all 'Done' all frames (new in 102.42)

rush -donemail

rush -donemail [email[,email..]] [jobid..] Set Job Done Mail. Changes who to send mail to when job is done. In version 102.40h+, this means when the job renders its last frame, or when the job is dumped. Which means if you requeue frames after a job is done, you will receive an email each time the last frame is rendered. To set several names, separate the names by commas. Each time you set the value, the previous value is overwritten. See DoneMail submit command for more info and examples. See also DumpMail submit command if you want mail sent only once, when the job is actually dumped. Done Mail Examples rush -donemail fred@foo.com,jack@foo.com Fred and Jack will receive mail when the current job is done. rush -donemail fred@foo.com tahoe.37 Fred will receive mail when jobid tahoe.37 is done. rush -donemail - tahoe.37 tahoe.38 Disable all done emails for jobids tahoe.37 and tahoe.38   See Also DoneMail -- Submit command defines who to send email to when job is done DumpMail -- Submit command defines who to send email to when job is dumped rush -dumpmail -- Command line flag changes who to send email when job is dumped

rush -down

rush -down downhost[,downhost..] jobhost A Machine Is Down. Tells rush jobs a machine is down. If a machine hangs or goes down, rush has no way to know it.. for all rush knows, the remote machine is just under heavy load, and is being unresponsive. Use '-down' to requeue frames in jobs that are stuck in the Run or Start state, because the remote machine is either hung or has been turned off unexpectedly. Normally frames will requeue when the remote is rebooted, but in cases where the machine needs to stay off for a while, the user can use '-down' to manually tell rush the remote is down, and to requeue the hung frames elsewhere. This also helps jobs that won't dump because some frames are 'stuck' on a host that is down. Warning: This command should only be used in extreme situations where job(s) show the frames running on a remote machine that is known to be down, or not running the frame. 'rush -down' Examples rush -down huron,erie tahoe   Tell all jobs on tahoe that machines    'huron' and 'erie' are down rush -down huron,erie +any Tell all hosts that 'huron' and 'erie' are down

rush -dump

rush -dump [jobid|user|user@host..] rush -dump - Dump Job. Dumps the job. Busy frames are killed right away. If no arguments are specified, the RUSH_JOBID variable is used to determine which job to dump. If jobid(s) are specified as arguments, those jobs will be dumped. If '-' is specified as an argument, jobids are read from stdin. (Useful if the list of jobids exceeds operating system limits for argument lists and environment variable sizes) If a user's name is specified as an argument, all jobs owned by that user on the local machine will be dumped (e.g., 'rush -dump fred'). If user@host is specified as an argument, all jobs owned by 'user' served by 'host' will be dumped. i.e., 'rush -dump fred@tahoe' will dump all jobs owned by fred that were submitted to host tahoe. 'rush -dump' Examples % rush -dump tahoe.37 tahoe.38    Dumps jobs tahoe.37 and tahoe.38 % rush -dump fred Dumps all jobs owned by 'fred' served by the local machine   % rush -dump fred@superior Dumps all jobs owned by 'fred' served by host 'superior'

rush -dumpmail

rush -dumpmail [email[,email..]] [jobid..] Set Job Dump Mail. Changes who to send mail to when job is dumped. To set several names, separate the names by commas. Each time you set the value, the previous value is overwritten. See DumpMail submit command for more info and examples. If you want mail sent whenever the job finishes rendering the last frame, then use instead -donemail. Dump Mail Examples rush -dumpmail fred@foo.com,jack@foo.com Fred and Jack will receive mail when the current job is dumped. rush -dumpmail fred@foo.com tahoe.37 Fred will receive mail when jobid tahoe.37 is dumped. rush -dumpmail - tahoe.37 tahoe.38 Disable all dump emails for jobids tahoe.37 and tahoe.38   See Also DoneMail -- Submit command defines who to send email to when job is done DumpMail -- Submit command defines who to send email to when job is dumped rush -donemail -- Command line flag changes who to send email when job is done

rush -end

rush -end [jobid..] rush -end - End Job. Ends a job. Similar to rush -dump, but lets running frames finish (i.e., running frames are not killed). See Also rush -dump -- Dump a job and kill running frames

rush -exitnotes

rush -exitnotes "text message" Exit Notes for frame. Use this from within render scripts as an alternative to 'rush -notes' to change the NOTES field of 'rush -lf' reports when a render script finishes rendering a frame. This command should ONLY be used from within a running render script to change the notes for the currently rendering frame just before the script is about to exit. Do NOT use this command to attempt to change frames in other jobs, or different frames within a job; use 'rush -notes' in such cases. The command will not take effect until the process actually exits; this is due to how the notes are delivered to the jobserver as part of the process exit code delivery. Unlike most rush commands, this command does not accept command line arguments to specify the jobid or frame number; it is assumed this command will only be run from within the render script during its execution, and it therefore uses the environment variables RUSH_JOBID and RUSH_FRAME (which are automatically in the render script's environment) to determine which job/frame to affect. For this reason, do not attempt to unset or modify these variables from within the render script, and do not attempt to force-set these variables in attempt to subvert this command to be used in other contexts. Example Use This command is safe to use within render scripts in both error and non-error conditions, since it is a low-bandwidth operation, so it can be used when 100's of machines are all rendering at the same time without negatively impacting the job server (as would be the case if 'rush -notes' were used) Example use of 'rush -exitnotes' #!/bin/csh -f ### RENDER SCRIPT # Render render //jobserver/jobs/inuyasha/s8a/dropshadow/${RUSH_PADFRAME}.rib set err = $status if ( $err != 0 ) then rush -exitnotes "Render failed: exitcode $err" exit 1 endif # Image integrity check imagecheck //jobserver/images/inuyasha/s8a/drop-${RUSH_PADFRAME}.sgi if ( $status ) then rush -exitnotes "Failed image check" exit 1 endif rush -exitnotes "Image check OK" exit 0 In the above case, as each frame finishes, the 'NOTES' field in the 'rush -lf' frames report might look like: Frames Report Showing -exitnotes % rush -lf STAT FRAME TRY HOSTNAME PID JOBID START ELAPSED NOTES Done 0001 2 ontario 19752 ontario.12 05/18,18:51:03 00:01:17 Image OK Done 0002 4 ontario 19763 ontario.12 05/18,18:51:05 00:01:15 Image OK Fail 0003 3 erie 11112 ontario.12 05/18,18:51:03 00:00:27 Failed image check Fail 0004 9 erie 11121 ontario.12 05/18,18:51:44 00:00:25 Failed image check Done 0005 10 cross 19779 ontario.12 05/18,18:52:23 00:00:02 Image OK Done 0006 3 cross 19781 ontario.12 05/18,18:52:23 00:00:02 Image OK Done 0007 2 cyanic 11129 ontario.12 05/18,18:52:22 00:00:25 Image OK New in Rush 103.06: If no frame# is specified, RUSH_FRAME will be used to determine which frame will be affected. Low Latency The use of this command within render scripts is low latency, and the specified notes get piggy-backed along with the exit codes returned to the job server when the render script exits. Before Rush 103.06, the 'rush -notes' command used TCP for communications, TCP being a higher latency protocol that could overload the job server if too many of these commands happened to run all at once across the farm. In Rush 103.06, the 'rush -notes' command now uses the lower latency UDP protocol, lessening the need for 'rush -exitnotes'. As well, 'rush -notes' takes effect immediately, making it more flexible should one want to adjust the notes /while/ a frame is rendering (something 'rush -exitnotes' does not support).

rush -fail

rush -fail <framerange|framestate..> [jobid..] Fail Frames. Changes frame(s) into the Fail state for current [specific] job. If frames are running, they are killed and enter the 'Fail' state on completion. The frames to affect can either be specified as a frame range (i.e., 1-100) or as a frame state, for which all matching frames will be affected. Examples: 'rush -fail' Examples % rush -fail 1-100 Fail frames 1 through 100 % rush -fail done Fail all frames currently Done % rush -fail done hold    Fail all frames currently Done or Hold   % rush -fail all Fail all frames (new in 102.42)

rush -fifo-order

rush -fifo-order <date|timeval> [jobid..] Fifo Ordering. (new in 103.06) Changes the FIFO ordering for a job when FIFO scheduling has been enabled by the administrator. By definition, a job's FIFO ordering value is determined by the date/time the job was submitted; jobs submitted first will be scheduled to run before jobs submitted later. This date oriented order can be changed while jobs are running to change the way jobs are scheduled to run by redefining the FIFO order date/time value to some new value. By default, the 'rush -fifo-order' command is only available to the rush administrators, but individual users can be added by the systems administrator; see FIFO ORDER SECURITY below. The new FIFO date can be specified either in MM/DD/YY[YY],HH:MM:SS format (e.g. "06/16/2014,10:48:20"), or as a unix time(2) value (e.g. 1402940900). Examples: 'rush -fifo-reorder' Examples % rush -fifo-reorder 06/16/2014,10:48:20 tahoe.12    Set FIFO order for jobid tahoe.12 to a specific date/time. % rush -fifo-reorder 1402940900 tahoe.12 Set FIFO order for jobid tahoe.12 to a specific time(2) value. FIFO ORDER SECURITY By default, the 'rush -fifo-order' command is made available to the rush administrators as defined by the rush.conf 'permit' command for the 'everything' keyword. However, specific usernames can be enabled to use this option with the permit 'fifo-order' keyword in the rush.conf file, e.g. Enabling Specific Users      permit { .. fifo-order: { jack jane wrangler1 wrangler2 } } To enable all users, '*' can be specified in place of specific usernames. Enabling All Users      permit { .. fifo-order: { * } } See Also: rush -fifo-order -- Re-order FIFO jobs fifo.reset -- Control when FIFO order value auto-resets sched fifo -- Enable FIFO scheduling FIFO Scheduling -- description of FIFO scheduling

rush -frameflags

rush -frameflags <-|keepnotes..> [jobid..] Change Frame Flags. Changes flags that affect frames. Frame Flags rush -frameflags keepnotes Disables automatic clearing of 'NOTES" field in framelist when a frame starts rendering. rush -frameflags - No flags. (Default) Default behavior is for NOTES field in framelist to be cleared    whenever a frame starts rendering. See Also FrameFlags -- Submit command to set the job's frame flags

rush -fu

rush [args..] -fu Force User1 The -fu flag augments other operations. It overrides warnings pertaining to lack of permission to do an operation because the user invoking it is not the owner of the job. For instance, if you want to control another person's job, you might get an error, e.g.: Using the 'rush -fu' Flag % rush -an vaio va-229 rush: va-229: you're not owner!   Attempt to add 'vaio' as a nevercpu to someone's job    fails because you're not the job's owner % rush -an vaio va.229 -fu         Add nevercpu 'vaio' Same command with -fu to force it... ...now it works Note: This feature may be disabled by the system administrator via the DisableFu flag in the Rush Configuration File. 1 This acronym is rumored to have an alternate, pejorative expansion. See Also $RUSH_FU -- An environment variable that enables FU mode DisableFu -- A rush config flag to let the admin disable FU mode

rush -getoff

rush -getoff [-foe] [-msg 'text'] [remotehost|+hostgroup..] Get Off A Machine. Similar to 'rush -offline', but kills and requeues any currently running frames before taking the specified host/hostgroups offline. If no hosts/hostgroups are specified, the local machine's rush daemon is taken offline. When a machine is taken offline, frames that are already rendering are allowed to complete before taking the processors offline. Once offline, no new frames will be started. [-foe] "Fail On Error". Causes the command to stop on any hostname lookup errors (such as temporary DNS or LDAP issues), instead of just printing warnings and continuing to run to handle any other hostnames specified. (default: off) *This flag new in 103.07* An optional remark can be specified via "-msg 'text'" which will show up in 'rush -lac' reports, eg: Using 'rush -getoff' with a Custom Message % rush -getoff -msg 'Client Demo' ontario ontario: Offline (killing 1 procs) % rush -lac HOST OWNER JOBID TITLE FRM PRI PID ELAPSED REMARKS ---------- -------- -------------- ------------------------- ---- ----- ------- ---------- -------- ontario - - - - - - Offline Client Demo : Examples of 'rush -getoff': 'rush -getoff' Examples % rush -getoff Kills frames running on localhost (requeing them elsewhere) leaving the localhost offline (won't accept any more renders) % rush -getoff tahoe erie      Kills frames running on tahoe and erie (requeing the frames elsewhere)    leaving both hosts offline (won't accept any more renders) % rush -getoff -msg 'Bad Memory' huron    Offline 'huron' with the remark 'Bad Memory' Changes to the online/offline state are appended to the rushd.log. Also: (new in 102.42a9), changes to the online/offline state append 's' entries to the cpu.acct accounting log

rush -hold

rush -hold <framerange|framestate..> [jobid..] Hold Frames. Changes frame(s) into the Hold state for current [specific] job. If frames are running, they are killed and enter the 'Hold' state on completion. When a frame is in the Hold state the frame will not be rendered, and a job will not autodump if there are any Hold frames in the frame list. The frames to affect can either be specified as a frame range (i.e., 1-100) or as a frame state, for which all matching frames will be affected. Examples: 'rush -hold' Examples % rush -hold 1-100 Hold frames 1 through 100 % rush -hold fail Hold all frames currently Fail % rush -hold fail done    Hold all frames currently Fail or Done   % rush -hold all Hold all frames (new in 102.42)

rush -imgcommand

rush -imgcommand 'command [args..]' [jobid..] rush -imgcommand [jobid..] < file Set Image Display Command Used by IRUSH to determine the command to execute whenever the user double clicks on a frame in the IRUSH 'Frames' report. Normally, the command invoked should display the rendered image for that frame. This should be a complete command to view an image in your favorite image viewer, with %d or %04d in place of the frame number. If 'cmd [args]' are not supplied, the command will be read from stdin. This is useful to avoid shell quoting issues. If multiple lines are specified, they will be joined into one single line. The image viewing command must background itself, or you must force it by using '&' (Unix), or 'start /b' (Windows). Examples: 'rush -imgcommand' Examples % rush -imgcommand 'xv /job/images/foo.%04d.sgi &' (Unix) Invokes 'xv' to view images C:\> rush -imgcommand "start /b flip //nt/images/s1.%04d.png" (Windows) Invokes 'flip' in background    to view images See Also ImgCommand -- Submit command sets the imgcommand used by irush

rush -jobcheckpoint

rush -jobcheckpoint [-foe] [host|+hostgroup..] Save all jobs to the checkpoint file This tells the local host (or remotehost|+hostgroup if specfied) to save a checkpoint now. Checkpoint will be loaded on reboot automatically, if the checkpoint.onboot is set to '1' in the rush.conf file (which is the default). [-foe] "Fail On Error". Causes the command to stop on any hostname lookup errors (such as temporary DNS or LDAP issues), instead of just printing warnings and continuing to run to handle any other hostnames specified. (default: off) *This flag new in 103.07*

rush -jobdata

rush -jobdata [-key keyname] 'data..' [jobid..] rush -jobdata [-key keyname] [jobid..] < data.txt rush -jobdata '-' [jobid..] Set Job Data. (New in 103.00) Appends free form strings of 'job data' to the current [specific] job. Job data is viewable in 'rush -ljf'. This is similar to '-jobnotes'; both keep track of strings of data in the same way. '-jobnotes' is intended for notes to users, or notes about the job. '-jobdata' is more for data communications between programs, such as data payloads to be injected into databases, or data used by GUIs such as IRUSH, submit forms, etc. If 'data..' is not specified, the data can be supplied on stdin. If 'data..' is specified on the command line, it must be quoted if it contains spaces. Specifing 'rush -jobdata -' will clear all previous data. (New in 103.06) The new "-key <keyname>" option allows one to change the contents of specific lines in the jobdata that start with the specified <keyname>, where lines are of the form 'keyname: value', example: % rush -ljf -fmt JobData tahoe.123 JobData[0]: SHOW: bigshow JobData[1]: SHOT: some shot JobData[2]: TD_NOTES: Awaiting approval % rush -jobdata -key TD_NOTES 'Director approved.' tahoe.123 tahoe.123: jobdata for 'TD_NOTES' is now 'Director approved.' % rush -ljf -fmt JobData tahoe.123 JobData[0]: SHOW: bigshow JobData[1]: SHOT: some shot JobData[2]: TD_NOTES: Director approved. Multiline data may also be modified with -key, e.g. % rush -ljf -fmt JobData tahoe.123 JobData[0]: SHOW: bigshow JobData[1]: SHOT: some shot JobData[2]: TD_NOTES: This is line one JobData[3]: TD_NOTES: This is line two JobData[4]: TD_NOTES: This is last line % cat /var/tmp/newnotes The special effects supe approved on Monday but the director asked for some mods. % cat /var/tmp/newnotes | rush -jobdata -key TD_NOTES tahoe.123 tahoe.123: jobdata for 'TD_NOTES' is now 'The special effects supe approved on Monday' tahoe.123: jobdata for 'TD_NOTES' is now 'but the director asked for some mods.' % rush -ljf -fmt JobData tahoe.123 JobData[0]: SHOW: bigshow JobData[1]: SHOT: some shot JobData[2]: TD_NOTES: The special effects supe approved on Monday JobData[3]: TD_NOTES: but the director asked for some mods. % rush -ljf -fmt 'JobData[TD_NOTES]' tahoe.123 JobData[TD_NOTES]: The special effects supe approved on Monday JobData[TD_NOTES]: but the director asked for some mods. Note: when using -key, it is best to use 'key: values' throughout the jobdata for a job, to avoid having any free-form data confused for key names. See JobData submit command for more info. 'rush -data' Examples rush -data < foo.txt Appends contents of foo.txt to job's data rush -jobdata 'MYPROG: Line one' rush -jobdata 'MYPROG: Line two' Appends two lines of text to the job's data You can dynamically modify the job data (e.g. insert, remove, reformat), using these steps: 1) Use 'rush tahoe.123 -ljf -fmt JobData > tmpfile' to get the current jobdata for jobid tahoe.123 into a file called tmpfile. 2) Rearrange/amend the data in tmpfile as needed. 3) Use 'rush -jobdata -' to clear the previous data. 4) Use 'rush tahoe.123 -jobdata < tmpfile' to update the job with the new data. See Also JobData -- Submit command sets the job's data rush -ljf -- Command line 'list job full', which includes jobdata

rush -jobnotes

rush -jobnotes [-key keyname] 'notes..' [jobid..] rush -jobnotes [-key keyname] [jobid..] < notes.txt rush -jobnotes '-' [jobid..] Set Job Notes. Appends free form strings of 'job notes' to the current [specific] job. Job notes are viewable in 'rush -ljf'. If 'notes..' are not specified, the notes can be supplied on stdin. If 'notes..' are specified on the command line, they must be quoted if they contain spaces. Specifing 'rush -jobnotes -' will clear all previous notes. (New in 103.06) The new "-key <keyname>" option allows one to change the contents of specific lines in the job notes that start with the specified <keyname>, where lines are of the form 'keyname: value', example: % rush -ljf -fmt Notes tahoe.123 Notes[0]: SHOW: bigshow Notes[1]: SHOT: some shot Notes[2]: TD_NOTES: Awaiting approval % rush -jobnotes -key TD_NOTES 'Director approved.' tahoe.123 tahoe.123: jobnotes for 'TD_NOTES' is now 'Director approved.' % rush -ljf -fmt Notes tahoe.123 Notes[0]: SHOW: bigshow Notes[1]: SHOT: some shot Notes[2]: TD_NOTES: Director approved. Multiline data may also be modified with -key, e.g. % rush -ljf -fmt Notes tahoe.123 Notes[0]: SHOW: bigshow Notes[1]: SHOT: some shot Notes[2]: TD_NOTES: This is line one Notes[3]: TD_NOTES: This is line two Notes[4]: TD_NOTES: This is last line % cat /var/tmp/newnotes The special effects supe approved on Monday but the director asked for some mods. % cat /var/tmp/newnotes | rush -jobnotes -key TD_NOTES tahoe.123 tahoe.123: jobnotes for 'TD_NOTES' is now 'The special effects supe approved on Monday' tahoe.123: jobnotes for 'TD_NOTES' is now 'but the director asked for some mods.' % rush -ljf -fmt Notes tahoe.123 Notes[0]: SHOW: bigshow Notes[1]: SHOT: some shot Notes[2]: TD_NOTES: The special effects supe approved on Monday Notes[3]: TD_NOTES: but the director asked for some mods. % rush -ljf -fmt 'Notes[TD_NOTES]' tahoe.123 Notes[TD_NOTES]: The special effects supe approved on Monday Notes[TD_NOTES]: but the director asked for some mods. Note: when using -key, it is best to use 'key: values' throughout the job notes for a job, to avoid having any free-form data confused for key names. See Notes submit command for more info. 'rush -jobnotes' Examples rush -jobnotes < foo.txt Set job notes to contents of foo.txt (Previous notes are completely cleared) rush -jobnotes 'This is a test' Set job notes to 'This is a test' You can dynamically modify the job notes (e.g. insert, remove, reformat), using these steps: 1) Use 'rush tahoe.123 -ljf -fmt Notes > tmpfile' to get the current job notes for jobid tahoe.123 into a file called tmpfile. 2) Rearrange/amend the notes in tmpfile as needed. 3) Use 'rush -jobnotes -' to clear the previous notes. 4) Use 'rush tahoe.123 -jobnotes < tmpfile' to update the job with the new notes. See Also Notes -- Submit command sets the job's 'notes' rush -ljf -- Command line flag to 'list job full', which shows the job 'notes'

rush -jobremarks

rush -jobremarks 'message_text' [jobid..] User Defined Job Remarks. (102.42a9 and up) Includes "message_text" in the "Remarks" field of the rush -lj/-laj reports. In the report, message_text will be enclosed in [brackets] to differentiate the user defined remarks from rush's own remarks (see example below). Historical Note: This feature was actually implemented in an earlier release, but fell out of subsequent releases up thru 102.42a8 due to a source code regression, and wasn't reinstated until 102.42a9. Example: 'rush -jobremarks' % rush -lj STATUS JOBID TITLE OWNER %DONE %FAIL BUSY ELAPSED REMARKS ------ -------- ---------- ------ ----- ----- ---- ---------- -------- Run tahoe.1 FG_PLATE erco %0 %0 8 00:05:53 Pause tahoe.2 BG_PLATE erco %10 %0 0 00:05:53 Job paused. Wait tahoe.3 COMP erco %0 %0 0 00:05:53 Wait for other jobs % rush -jobremarks "jason: please pickup" tahoe.1 tahoe.2 tahoe.3 tahoe.1: jobremarks is now 'jason: please pickup' tahoe.2: jobremarks is now 'jason: please pickup' tahoe.3: jobremarks is now 'jason: please pickup' % rush -lj STATUS JOBID TITLE OWNER %DONE %FAIL BUSY ELAPSED REMARKS ------ -------- ---------- ------ ----- ----- ---- ---------- -------- Run tahoe.1 FG_PLATE erco %0 %0 8 00:05:53 [jason: please pickup] Pause tahoe.2 BG_PLATE erco %10 %0 0 00:05:53 [jason: please pickup] Job paused. Wait tahoe.3 COMP erco %0 %0 0 00:05:53 [jason: please pickup] Wait for other jobs See Also jobremarks -- Submit command to set job's remarks rush -lj -- Command line flag to list jobs, which includes 'job remarks'

rush -jobrestartcommand

rush [jobid] -jobrestartcommand 'command [args..]' rush [jobid] -jobrestartcommand < file rush [jobid] -jobrestartcommand '-' Set the command executed when job restarts running. See JobRestartCommand submit command for more info. This allows a command to be executed if a job has completed, and someone restarts it by requeueing one or more frames. If 'cmd [args]' are not supplied, the command will be read from stdin. This is useful to avoid shell quoting issues. If multiple lines are specified, they will be joined into one single line. Setting the jobrestartcommand to '-' will disable it. Examples: 'rush -jobrestartcommand' Examples rush -jobrestartcommand 'perl //server/share/rush/restart.pl'   Set jobrestartcommand to run a perl script rush -jobrestartcommand < foo.txt Set jobrestartcommand to contents of foo.txt   rush -jobrestartcommand - disable the jobrestartcommand (Default) See Also JobRestartCommand -- Submit command to set command to run when job restarts rush -jobrestartcommandflags -- Sets flags that affect how the jobrestartcommand is executed

rush -jobrestartcommandflags

rush -jobrestartcommandflags option[,option] [jobid..] Set Job Restart Command Flags. (New in 103.00) Sets optional flags that affect how the jobrestartcommand is executed. The specified flags are logically 'OR'ed to augment existing flags. So if the current flags are 'quote,escape', and you then run 'rush -jobrestartcommandflags useshell,quote', the result will leave 'quote,escape,useshell' enabled. If you want to set ONLY the flags you specify, precede your list of flags with 'off' to zero out any existing flags first. Then your flag specifications will be appended to that. (Note: flags are parsed left-to-right, so you want 'off' to be first in the list). So if the current flags are 'quote,escape', and you run 'rush -jobrestartcommandflags off,quote,useshell', the result will leave only 'quote,useshell' enabled. The following options are supported, which can be separated by commas to specify several at a time: -jobrestartcommandflags Options quote Honor double quotes in the command. This can be used to protect spaces in command arguments. escape Honor escape characters (\) in the command. Use this to escape certain characters (like '$' and '"'). Use this to protect quotes-within-quotes (if 'quote' is specified) and to protect '$' (if 'expandvars' is specified) expandvars Expand environment variables in the command. before it's executed. Variables can be specified in the format ${VARNAME} across both platforms. useshell Run the command in a native shell. Under windows this means a DOS "cmd" shell. Under unix this means a Bourne /bin/sh. off Disable all command flags. Use this at the beginning of your list of flags

rush -jobstartcommand

rush [jobid] -jobstartcommand 'command [args..]' rush [jobid] -jobstartcommand < file rush [jobid] -jobstartcommand '-' Set the command executed when job starts running. See JobStartCommand submit command for more info. A job might not start running right away, such as if the job has a 'waitfor' command defined. If 'cmd [args]' are not supplied, the command will be read from stdin. This is useful to avoid shell quoting issues. If multiple lines are specified, they will be joined into one single line. Setting the jobstartcommand to '-' will disable it. Examples: 'rush -jobstartcommand' Examples rush -jobstartcommand 'perl //server/share/rush/start.pl'   Set job start command to run a perl script rush -jobstartcommand < foo.txt Set job start command to contents of foo.txt   rush -jobstartcommand - disable the start command (Default) See Also JobStartCommand -- Submit command to set command to run when job starts running rush -jobstartcommandflags -- Sets flags that affect how the jobstartcommand is executed WaitFor -- Submit command to make a job wait for a specific time or for other jobs

rush -jobstartcommandflags

rush -jobstartcommandflags option[,option] [jobid..] Set Job Start Command Flags. (New in 103.00) Sets optional flags that affect how the JobStartCommand is executed. The specified flags are logically 'OR'ed to augment existing flags. So if the current flags are 'quote,escape', and you then run 'rush -jobstartcommandflags useshell,quote', the result will leave 'quote,escape,useshell' enabled. If you want to set ONLY the flags you specify, precede your list of flags with 'off' to zero out any existing flags first. Then your flag specifications will be appended to that. (Note: flags are parsed left-to-right, so you want 'off' to be first in the list). So if the current flags are 'quote,escape', and you run 'rush -jobstartcommandflags off,quote,useshell', the result will leave only 'quote,useshell' enabled. The following options are supported, which can be separated by commas to specify several at a time: -jobstartcommandflags Options quote Honor double quotes in the command. This can be used to protect spaces in command arguments. escape Honor escape characters (\) in the command. Use this to escape certain characters (like '$' and '"'). Use this to protect quotes-within-quotes (if 'quote' is specified) and to protect '$' (if 'expandvars' is specified) expandvars Expand environment variables in the command. before it's executed. Variables can be specified in the format ${VARNAME} across both platforms. useshell Run the command in a native shell. Under windows this means a DOS "cmd" shell. Under unix this means a Bourne /bin/sh. off Disable all command flags. Use this at the beginning of your list of flags

rush -jobdonecommand

rush [jobid] -jobdonecommand 'command [args..]' rush [jobid] -jobdonecommand < file rush [jobid] -jobdonecommand '-' rush [jobid] -jobdonecommand '[options] command [args]' Set the command executed when job done running. See JobDoneCommand submit command for more info. If 'command [args..]' are not supplied, the command will be read from stdin; useful to avoid shell quoting issues. If multiple lines are specified, they will be joined into a single line. Setting the jobdonecommand to '-' will disable it. Examples: 'rush -jobdonecommand' Examples rush -jobdonecommand 'perl //server/share/rush/done.pl' Set job done command to run a perl script rush -jobdonecommand < foo.txt Set job done command to contents of foo.txt   rush -jobdonecommand - Disable the job done command (Default) By default, the jobdonecommand is executed whenever the last running frame finishes. This behavior can be redefined by specifying [options] before the 'command [args..]': -jobdonecommand Options  -nolog  Disables creation of jobdonecommand.log in the log directory. Here are some examples with [options] specified: Example JobDoneCommand With Options rush -jobdonecommand '-nolog perl //path/mydonecommand.pl' Disables the logging to 'jobdonecommand.log', so cleanup avoids Windows 'file in use' errors. See Also JobDoneCommand -- Submit command to set command to run when job renders last frame rush -jobdonecommandflags -- Sets flags that affect how the jobdonecommand is executed

rush -jobdonecommandflags

rush -jobdonecommandflags option[,option] [jobid..] Set Job Done Command Flags. (New in 103.00) Sets optional flags that affect how the JobDoneCommand is executed. The specified flags are logically 'OR'ed to augment existing flags. So if the current flags are 'quote,escape', and you then run 'rush -jobdonecommandflags useshell,quote', the result will leave 'quote,escape,useshell' enabled. If you want to set ONLY the flags you specify, precede your list of flags with 'off' to zero out any existing flags first. Then your flag specifications will be appended to that. (Note: flags are parsed left-to-right, so you want 'off' to be first in the list). So if the current flags are 'quote,escape', and you run 'rush -jobdonecommandflags off,quote,useshell', the result will leave only 'quote,useshell' enabled. This command has some other special flags the other commands do not support that are mutually exclusive: done,donefail,fail,always. (see table below) Only one of these flags can be on at a time, and 'always' is the default. The following options are supported, which can be separated by commas to specify several at a time: -jobdonecommandflags Options quote Honor double quotes in the command. This can be used to protect spaces in command arguments. escape Honor escape characters (\) in the command. Use this to escape certain characters (like '$' and '"'). Use this to protect quotes-within-quotes (if 'quote' is specified) and to protect '$' (if 'expandvars' is specified) expandvars Expand environment variables in the command. before it's executed. Variables can be specified in the format ${VARNAME} across both platforms. useshell Run the command in a native shell. Under windows this means a DOS "cmd" shell. Under unix this means a Bourne /bin/sh. off Disable all command flags. Use this at the beginning of your list of flags These additional flags are mutually exclusive: JobDoneCommandFlags that control exexcution based on job state These flags are mutually exclusive. done Runs jobdonecommand only if all frames are "Done" fail Runs jobdonecommand only if *any* frames are "Fail" and rest are "Done" donefail Runs jobdonecommand only if all frames are either "Done" "Fail" always Runs jobdonecommand when job is done, regardless of the state of the frames (Default) (If job is dumped while frames are still 'Que', command will still run)

rush -jobdumpcommand

rush [jobid] -jobdumpcommand '[-nolog] command [args..]' rush [jobid] -jobdumpcommand < file rush [jobid] -jobdumpcommand '-' Set the command executed when job dumps. See JobDumpCommand submit command for more info. If 'cmd [args]' are not supplied, the command will be read from stdin. This is useful to avoid shell quoting issues. If multiple lines are specified, they will be joined into one single line. Specifying the '-nolog' option in front of 'command' will disable the creation of the 'jobdumpcommand.log' file in the LogDir. This is useful to prevent 'file in use' errors on Windows if you want to remove the entire logdir as part of a cleanup operation. Setting the jobdumpcommand to '-' will disable it. Examples: 'rush -jobdumpcommand' Examples rush -jobdumpcommand 'perl //server/share/rush/dump.pl' Set job dump command to run a perl script rush -jobdumpcommand '-nolog perl //server/share/rush/dump.pl' Same as above, disables creation of 'jobdumpcommand.log' rush -jobdumpcommand < foo.txt Set job dump command to contents of foo.txt rush -jobdumpcommand - Disable the dump command (Default)   See Also JobDumpCommand -- Submit command to set command to run when job is dumped rush -jobdumpcommandflags -- Sets flags that affect how the jobdumpcommand is executed

rush -jobdumpcommandflags

rush -jobdumpcommandflags option[,option] [jobid..] Set Job Dump Command Flags. (New in 103.00) Sets optional flags that affect how the JobDumpCommand is executed. The specified flags are logically 'OR'ed to augment existing flags. So if the current flags are 'quote,escape', and you then run 'rush -jobdumpcommandflags useshell,quote', the result will leave 'quote,escape,useshell' enabled. If you want to set ONLY the flags you specify, precede your list of flags with 'off' to zero out any existing flags first. Then your flag specifications will be appended to that. (Note: flags are parsed left-to-right, so you want 'off' to be first in the list). So if the current flags are 'quote,escape', and you run 'rush -jobdumpcommandflags off,quote,useshell', the result will leave only 'quote,useshell' enabled. The following options are supported, which can be separated by commas to specify several at a time: -jobdumpcommandflags Options quote Honor double quotes in the command. This can be used to protect spaces in command arguments. escape Honor escape characters (\) in the command. Use this to escape certain characters (like '$' and '"'). Use this to protect quotes-within-quotes (if 'quote' is specified) and to protect '$' (if 'expandvars' is specified) expandvars Expand environment variables in the command. before it's executed. Variables can be specified in the format ${VARNAME} across both platforms. useshell Run the command in a native shell. Under windows this means a DOS "cmd" shell. Under unix this means a Bourne /bin/sh. off Disable all command flags. Use this at the beginning of your list of flags

rush -lac

rush -lac [-s secs] [-r retry] [-c count] [-foe] List All Cpus. Lists the status of all rush cpus on the network. Report should come up quickly, even on large networks. This report is useful for seeing which cpus are running whose jobs. [-r secs] is an optional argument specifying the number of times to retry contacting the remote machine, before giving up. Default is 4. [-s secs] is an optional argument specifying the number of seconds between retries for remotes that don't respond right away. Default is 2. [-c count] is an optional argument to specify the number of times to automatically regenerate the report (for continuous updates). A value of 0 indicates infinite updating. Default is 1. Example report: [-foe] "Fail On Error". Causes the command to stop on any hostname lookup errors (such as temporary DNS or LDAP issues), instead of just printing warnings and continuing to run to handle any other hostnames specified. (default: off) *This flag new in 103.07* 'rush -lac' Report % rush -lac HOST OWNER JOBID TITLE FRM PRI PID ELAPSED tahoe - - - - - - Online tahoe - - - - - - Online superior erco vaio.50 FOREST_RENDER 0034 100 4026 00:10:01 superior erco vaio.50 FOREST_RENDER 0035 100 4027 00:10:02 superior tamu ibm4.208 AUTO_CAD 0101 300k 2031 02:43:31 superior tamu ibm4.208 AUTO_CAD 0102 300k 2035 02:43:31 erie erco vaio.50 FOREST_RENDER 0041 900k 14560 00:10:15 erie erco vaio.50 FOREST_RENDER 0042 900k 14561 00:10:15 michigan - - - - - - Offline michigan - - - - - - Offline michigan - - - - - - Offline michigan - - - - - - Offline *** NO RESPONSE FROM: *** ontario huron Note that machines that did not respond are listed in the summary at the bottom of the report; all lines of these summaries are prefixed by '***'. All Cpus Report Format The administrator has a certain amount of control over the output format of the 'All Cpus' report via the rush.conf file, specifically with the AllCpusFmt, AllCpusHeader1, AllCpusHeader2 commands.

rush -lacf

rush -lacf [-s secs] [-r retry] [-c count] List All Cpus Full. Lists the full info of all rush cpus on the network. This report may take a while to run. This report prints out more information than people usually need. This command is more intended to either be parsed by external scripts needing access to all information rush can provide, or for debugging. [-r secs] is an optional argument specifying the number of times to retry contacting the remote machine, before giving up. Default is 4. [-s secs] is an optional argument specifying the number of seconds between retries for remotes that don't respond right away. Default is 2. [-c count] is an optional argument to specify the number of times to automatically regenerate the report (for continuous updates). A value of 0 indicates infinite updating. Default is 1.

rush -lah

rush -lah [-t timeout] [hostname..|+hostgroup..] List All Hosts. Lists the Ram/Criteria configuration for all hosts in the render queue, which is loaded directly from the $RUSH_DIR/etc/hosts file. Example: 'rush -lah' Report % rush -lah IP Hostname Ram Cpus MinPri Criteria 10.100.100.1 tahoe 512 2 0 +any,irix 10.100.100.2 superior 512 2 0 +any,irix,+dante 10.100.100.3 erie 512 2 0 +any,irix,+dante 10.100.100.4 ontario 512 2 0 +any,irix,+dante 10.100.100.5 vaio 128 1 0 +any,linux,intel 10.100.100.6 rotwang 128 1 100 +any,linux,intel     Use '-t timeout' to control the amount of time rush waits to make a connection to each remote before it gives up. The default is 40 seconds. If hostname is specified, i.e., 'rush -lah hostname', the output comes from the cache of the daemon running on the specified host. This is useful in determining hostname caching problems. If a +hostgroup is specified, i.e. 'rush -lah +farm', the output comes from the cache of the daemons in that hostgroup. A daemon's current negative hostname cache will be shown at the bottom of an -lah report, if the 'rush -lah <hostname>' syntax is used. The following example shows 3 negative cache entries ("geneeva", "thoe", and "foobar") as being cached by the daemon on host 'tahoe': Negative Cache % rush -lah tahoe Cache on tahoe: IP Hostname Ram Cpus MinPri Criteria 192.168.0.10 geneva 1024 2 0 +any,+w2k,+work 192.168.0.3 rotwang 100 2 0 +any,+erco,+linux,linux,linux6.0,intel,dante 192.168.0.9 ontario 100 2 0 +any,+erco,+linux,linux,linux6.0,intel,dante 192.168.0.14 meade 512 2 0 +any,+erco,+linux,linux 192.168.0.7 tahoe 512 2 0 +any,+erco,+linux,linux *** Negative Cache: geneeva (expires 00:12:38 secs from now) *** Negative Cache: thoe (expires 00:14:53 secs from now) *** Negative Cache: foobar (expires 00:14:53 secs from now) When too many hosts have been added to the rush/etc/hosts file than one is licensed for, rush simply ignores the extra hosts, and the 'rush -lah' report will warn about the extras in its report: Warnings for Unlicensed Hosts % rush -lah IP Hostname Ram Cpus MinPri Criteria 192.168.0.10 geneva 1024 2 0 +any,+w2k,+work 192.168.0.3 rotwang 100 2 0 +any,+erco,+linux,intel,dante 192.168.0.9 ontario 100 2 0 +any,+erco,+linux,intel,dante [..] 192.168.5.132 r0129 100 1 0 +any,+sgi 192.168.5.133 r0130 100 1 0 +any,+sgi *** ERROR: TOO MANY HOSTS IN RUSH HOSTS LIST [24 found, 20 max] *** ERROR: The following hosts are being ignored by rush.. *** 192.168.5.134 r0131 100 1 0 +any,+sgi *** 192.168.5.135 r0132 100 1 0 +any,+sgi *** 192.168.5.136 r0133 100 1 0 +any,+sgi *** 192.168.5.137 r0134 100 1 0 +any,+sgi

rush -lahf

rush -lahf [-t timeout] [hostname..] List All Hosts Full. Full hosts report for all hosts on local [remote] host. This report prints out more information than people usually need. This command is more intended to either be parsed by external scripts needing access to all information rush can provide, or for debugging. Use '-t timeout' to control the amount of time rush waits to make a connection to each remote before it gives up. The default is 40 seconds.

rush -laj

rush -laj [-fmt str|env|defaults|help] [-x] [-s secs] [-r retry] [-c count] [-r retries] [-foe] [hostname..|+hostgroup..] List All Jobs. Queries all hosts on the network for what jobs are running. (All hosts being all hosts in the "+any" hostgroup) [-x] is an optional 'extended report' flag that includes job progress bars; 'blue' indicates frames rendering, 'green' indicates frames done successfully, 'red' indicates failed frames. These colors will appear in irush reports and terminals that support "ANSI" colors or XTERM colors. For examples, see 'rush -lj' [-fmt str] is an optional flag to control the formatting of the report. You can choose which fields to show from a table of possible field names, allowing you to completely customize the report. If '-fmt env' is used, then the environment variable RUSH_LAJ_FMT will be read for the format info. Example: 'export RUSH_LAJ_FMT="Jobid Title"; rush -laj -fmt env' rush -laj options Option Description -x Extended report that includes job progress bars. -fmt str Sets a custom report formatting string. Same format as the 'rush -lj' report; see that for more info. Example: rush -laj -fmt "Jobid:-10 Status:-8 Title:-20 Progress:-20" The special flag "-fmt env" lets you use define the field names in the RUSH_LAJF_FMT environment variable, to avoid having to specify the flags on the command line each time. Example: 'export RUSH_LAJ_FMT="Jobid Title"; rush -laj -fmt env' The special flag "-fmt help" lists the format syntax and field names. The special flag "-fmt defaults" forces the software's built in format defaults. -c cnt Sets the number of times to continuously update the report. A value of zero ("-c 0") creates a continuous update. Default is 1, as defined by the rush.conf rush.laj_count command. -s secs Sets the floating point number of seconds between polls. Use with -c to poll automatically at a specified interval. Default is defined by the rush.conf rush.laj_secs command. -r secs Sets the number of times to retry contacting the remote machine before giving up. Default is defined by the rush.conf rush.laj_retry command. -ss secs Sets the floating point number of seconds between udp acknowledges. You probably don't want to mess with this unless you're getting weird communications behavior. Default is 0.05. -foe "Fail On Error". Causes the command to stop on hostname errors instead of continue to run for any other hostnames that resolve correctly. (default: off) *This flag new in 103.07* Optional hostnames or +hostgroups can be specified to list jobs served by only those hosts. If unspecified, all hosts in the +any group is used. 'rush -laj' Report % rush -laj STATUS JOBID TITLE OWNER %DONE %FAIL BUSY ELAPSED Run erie.167 100/340/master tamu %18 %0 8 01:15:28 Run erie.169 100/410/master tamu %75 %0 20 01:11:21 Run erie.170 100/390/master tamu %10 %34 4 01:10:44 Run erie.171 100/360/master tamu %10 %34 4 01:02:43 Run huron.454 W:090/440/all krement %100 %0 0 26:25:31 Run huron.457 W:090/425/master krement %100 %0 0 26:11:59 Run huron.476 W:090/425/master krement %100 %0 0 23:40:37 Run huron.519 Q:090/460/master krement %5 %0 8 00:21:27 Pause tahoe.76 230/250/layout_lock erco %2 %0 0 01:52:08 Run allek.790 qr2 tje %80 %1 4 06:58:20 Run allek.794 180/260/DAY tje %80 %1 2 06:38:48 Run allek.796 180/250/DAY tje %0 %0 0 06:34:21 Run allek.801 qr2 tje %0 %0 0 05:27:40 Run vaio.663 230/tdcheck/roomBC woz %80 %20 0 00:44:53 % rush -laj -fmt "Jobid:-12 Title" Jobid Title erie.167 100/340/master erie.169 100/410/master erie.170 100/390/master erie.171 100/360/master huron.454 W:090/440/all huron.457 W:090/425/master huron.476 W:090/425/master huron.519 Q:090/460/master tahoe.76 230/250/layout_lock allek.790 qr2 allek.794 180/260/DAY allek.796 180/250/DAY allek.801 qr2 vaio.663 230/tdcheck/roomBC All Jobs Report Format The administrator has a certain amount of control over the output format of the 'All Jobs' report via the rush.conf file, specifically with the rush.lj.fmt and rush.lj_x.fmt commands. Caveats Previously, this report used UDP exclusively. As of 102.42a9d2 / 103.03 and up, this report uses a combo of UDP and TCP; UDP is used to quickly identify machines that have jobs, then TCP is used to pull the report from those machines that responded over UDP that are managing any jobs. This is because often reports were so large, they were too large to send efficiently over UDP.

rush -lajf

rush -lajf [-s secs] [-c count|0] [-r retrycount] [-t timeout] [-fmt str|env|defaults|help] [hosts|+hostgroups..] List All Jobs Full. Full job report for all jobs on the network. This report may take a while to run. This report prints out more information than people usually need. This command is more intended to either be parsed by external scripts needing access to all information rush can provide, or for debugging. Optional hostnames or +hostgroups can be specified to list jobs served by only those hosts. If unspecified, all hosts in the +any group is used. [-fmt str] is an optional flag to limit the report to only show specific fields. (If unspecified, ALL fields are shown.) You can choose any of the field names from the 'rush -lajf' report separated by spaces, e.g. -fmt "Jobid Title Status WaitFor" which will limit the report to only show those four fields. This is similar to 'grep'ing for the fields you want, but more efficient because it avoids unnecessary network traffic for the unneeded data, making for a faster report. rush -lajf options Option Description -fmt str Sets a custom report formatting string. Same format as the 'rush -ljf' report; see that for more info. Example: rush -lajf -fmt "Jobid Title Status" The special flag "-fmt env" lets you use define the field names in the RUSH_LAJF_FMT environment variable, to avoid having to specify the flags on the command line each time. Example: 'export RUSH_LAJF_FMT="Jobid Title"; rush -lajf -fmt env' The special flag "-fmt defaults" forces the software's built in format defaults (all fields shown). -c cnt Sets the number of times to continuously update the report. Default is 1. -c 0 creates a continuous update. -s secs Sets the floating point number of seconds between polls. Use with -c to poll automatically at a specified interval. Default is 3.0. -r secs Sets the number of times to retry contacting the remote machine before giving up. Default is 2. -t timeout Sets the number of seconds to wait for response from server before giving up. Default is 40. 'rush -lajf' Report % rush -lajf Jobid: zoar.1 State: Done ActState: Done RebootId: 2076 Title: TEST_0001 DefPriority: 1 [..snip..] Cpus: +any=1@100 Cpus: +any=1@200 Criteria: Jobid: zoar.2 State: Done ActState: Done RebootId: 28 Title: TEST_0002 DefPriority: 1 [..snip..] Cpus: +any=10@100 Criteria: % rush -lajf -fmt "Jobid Title Cpus" Jobid: zoar.1 Title: TEST_0001 Cpus: +any=1@100 Cpus: +any=1@200 Jobid: zoar.2 Title: TEST_0002 Cpus: +any=10@100 Caveats Up until Rush 103.03, this report used UDP exclusively. As of 103.03 and up, this report uses a combo of UDP and TCP; UDP is used to quickly identify machines that have jobs, then TCP is used to pull the report from those machines that responded over UDP that are managing any jobs. This is because often reports were so large, they were too large to send efficiently over UDP.

rush -lc

rush -lc [-t timeout] [hosts..|+hostgroups|jobids..] List Cpus. Lists the cpus the job requested to use, and the status of those requests, i.e. busy, or if they were turned down for some reason (shown in the NOTES field). If one or more space-delimited [hosts..] are specified, the cpus of all jobs being managed by those hosts are shown. If one or more space-delimited [jobids..] are specified, only the cpus requested by those jobs are listed. If neither [hosts..] or [jobids..] are specified, the contents of the RUSH_JOBID environment variable is checked for jobids, and the cpu requests of only those jobs are reported. If none of the above are available, an error is reported Use '-t timeout' to control the amount of time rush waits to make a connection to each remote before it gives up. The default is 40 seconds. Example: 'rush -lc' Report % rush -lc tahoe.1 # List Cpus for job tahoe.1 CPUSPEC[HOST] STATE FRAME PID JOBTID PRI ELAPSED JOBID NOTES huron=4@800k JobPass - - 178 1 00:00:00 tahoe.1 This is a 'neverhost' huron=4@800k JobPass - - 179 1 00:00:00 tahoe.1 This is a 'neverhost' huron=4@800k JobPass - - 180 1 00:00:00 tahoe.1 This is a 'neverhost' huron=4@800k JobPass - - 181 1 00:00:00 tahoe.1 This is a 'neverhost' +farm=10@100[howland] Busy 0080 14733 165 1 00:00:01 tahoe.1 +farm=10@100[howland] Busy 0078 14731 166 1 00:00:01 tahoe.1 +farm=10@100[howland] Busy 0079 14732 167 1 00:00:01 tahoe.1 +farm=10@100[toronto] Idle/Nak - - 171 1 00:00:00 tahoe.1 - +farm=10@100[toronto] Idle/Nak - - 172 1 00:00:00 tahoe.1 - +farm=10@100[toronto] Idle/Nak - - 173 1 00:00:00 tahoe.1 - +farm=10@100[vaio] Busy 0074 4107 174 1 00:00:03 tahoe.1 +farm=10@100[vaio] Busy 0071 4100 175 1 00:00:03 tahoe.1 +farm=10@100[vaio] Busy 0072 4101 176 1 00:00:03 tahoe.1 +farm=10@100[vaio] Busy 0073 4106 177 1 00:00:03 tahoe.1 % rush -lc tahoe # List Cpus for /all/ jobs managed by host 'tahoe' CPUSPEC[HOST] STATE FRAME PID JOBTID PRI ELAPSED JOBID NOTES _ huron=4@800k JobPass - - 178 1 00:00:04 tahoe.1 This is a 'neverhost' | huron=4@800k JobPass - - 179 1 00:00:04 tahoe.1 This is a 'neverhost' | huron=4@800k JobPass - - 180 1 00:00:04 tahoe.1 This is a 'neverhost' | huron=4@800k JobPass - - 181 1 00:00:04 tahoe.1 This is a 'neverhost' | +farm=10@100[howland] Busy 0080 14733 165 1 00:00:05 tahoe.1 | +farm=10@100[howland] Busy 0078 14731 166 1 00:00:05 tahoe.1 | +farm=10@100[howland] Busy 0079 14732 167 1 00:00:05 tahoe.1 |-- job tahoe.1    +farm=10@100[toronto] Idle/Nak - - 171 1 00:00:04 tahoe.1 - | +farm=10@100[toronto] Idle/Nak - - 172 1 00:00:04 tahoe.1 - | +farm=10@100[toronto] Idle/Nak - - 173 1 00:00:04 tahoe.1 - | +farm=10@100[vaio] Busy 0074 4107 174 1 00:00:07 tahoe.1 | +farm=10@100[vaio] Busy 0071 4100 175 1 00:00:07 tahoe.1 | +farm=10@100[vaio] Busy 0072 4101 176 1 00:00:07 tahoe.1 | +farm=10@100[vaio] Busy 0073 4106 177 1 00:00:07 tahoe.1 _| +farm=10@100.1[howland] Idle - - 195 1 00:00:00 tahoe.2 _ +farm=10@100.1[toronto] Idle - - 192 1 00:00:00 tahoe.2 |-- job tahoe.2 +farm=10@100.1[vaio] Idle - - 194 1 00:00:00 tahoe.2 _| % rush -lc +work -t 3 # List Cpus for /all/ jobs managed by hosts in the +work group [..large report..] List Cpus Headings Heading Description CPUSPEC[HOST] The cpu specification supplied by the user during submit. If hostgroups are specified (i.e. +any), the group is broken out into individual cpus, with the hostname of each processor shown in [brackets]. STATE The state the cpu's 'task reservation' is in. In the following, 'cpuserver' means the remote host serving the cpu. Idle -- task idle, waiting for cpuserver Idle/Nak -- job is still trying to reach the cpuserver Avail -- cpuserver wants us to run a frame Start -- found frame to start, reply to cpuserver Run -- cpuserver telling us frame started ok Busy -- frame is busy, reply to cpuserver CpuPass2 -- replies to cpuserver, remains in state JobPass -- job told cpuserver we can't use its cpu (see NOTES for why) Unpass -- remote reverting to idle state (cosmetic) FRAME The frame that is being rendered. PID The process id on HOST for the running render script. This is also the 'process group leader'. JOBTID The 'job task id' for this processor. Only useful as an argument commands like 'rush -rc'. PRI The priority being requested ELAPSED The wall clock elapsed time in hours:minutes:seconds for the rendering frame. JOBID The jobid of the job (useful when more than one jobid is being reported) NOTES Various notes regarding the state of the job. These notes can sometimes be stale; the 'STATE' information is a more accurate representation of the state of the cpu. Some examples of the 'NOTES' column in the 'rush -lc' report: List Cpus Notes Field Message Description   Cpu max (#/# busy)   Job could not run on available cpu because the job's cpu cap (left value) has been reached; there are already cpus busy (right value). Examples: "Cpu max (2/2 busy)" -- job has 2 cpus busy, cap was set to 2. Typical case where the job is already rendering on as many cpus as it requested. "Cpu max (4/2 busy)" -- job has 4 cpus busy, and cap was set to 2. (This can happen if the cap was recently lowered from 4 to 2, while 4 were already busy.   Below MinPri (#<#)   Machine became available, but this job was turned away because the cpu's priority was less-than the minimum priority (MinPri) set by the sysadmin for this host in the rush/etc/hosts file.   Job state is 'pause'     Job state is 'wait'   ..etc.. Job can't run because the job is in the state shown. For instance, 'pause' indicates the job was paused at the time the cpu became available to run this job, so it was turned down.   No more frames   Job can't run because all the frames in the job have already been rendered at the time the cpu became available.   Maxcpus reached (#/#)   Job can't use the available cpu because the job already has enough cpus busy running to fulfill the 'maxcpus' set for the job. The two values shown (#/#): the 'maxcpus' for the job followed by the number of cpus the job had busy at the time the cpu became available.   This is a 'nevercpu'   Job can't use the available cpu because the job has this machine blacklisted in its 'nevercpus' (rush -an).   Failed 'criteria' check   Job can't use the available cpu because the job's configured 'criteria' didn't meet the machine's criteria configured in the rush/etc/hosts file.

rush -lcf

rush -lcf [-t timeout] [jobid..] List Cpus Full. A 'full' report for all of the current [specific] job's cpus. This report prints out more information than people usually need. This command is more intended to either be parsed by external scripts needing access to all information rush can provide, or for debugging. Use '-t timeout' to control the amount of time rush waits to make a connection to each remote before it gives up. The default is 40 seconds.

rush -lf

rush -lf [-t timeout] [jobid..] List Frames. Lists a job's frames to see what state they're in. The default is to show all the job's frames, but optional frame range(s) can be specified to limit the report. If a jobid is not specified, the RUSH_JOBID variable will be used. If multiple jobids are specified, the frames in each are listed. 'rush -lf' Report $ rush -lf              # List Frames for the current job STATUS FRAME TRY HOSTNAME PID JOBID START ELAPSED NOTES Run 5000 1 vaio 18092 tahoe.34 02/26,02:15:40 00:00:21 - Run 5001 1 vaio 18093 tahoe.34 02/26,02:15:40 00:00:21 - Run 5002 1 vaio 18100 tahoe.34 02/26,02:15:50 00:00:11 - Que 5003 0 - 0 tahoe.34 00/00,00:00:00 00:00:00 - Que 5004 0 - 0 tahoe.34 00/00,00:00:00 00:00:00 - Que 5005 0 - 0 tahoe.34 00/00,00:00:00 00:00:00 - $ rush -lf 5003-5005     # show only frames 5003 thru 5005 STATUS FRAME TRY HOSTNAME PID JOBID START ELAPSED NOTES Que 5003 0 - 0 tahoe.34 00/00,00:00:00 00:00:00 - Que 5004 0 - 0 tahoe.34 00/00,00:00:00 00:00:00 - Que 5005 0 - 0 tahoe.34 00/00,00:00:00 00:00:00 - (New in rush 102.42a9c and up) The -x flag includes optional 'extended' information at the bottom of the report; if the job has a 'jobstartcommand', 'jobrestartcommand', 'jobdonecommand', or 'jobdumpcommand' command configured, and the logs exist, these are shown as separate entries at the bottom of the -lf report. (IRUSH makes use of this, to allow the user to double-click on these lines in the 'Frames' report to view the contents of those log files.) Example: 'rush -lf -x' Report $ rush -lf -x           # include extended info STATUS FRAME TRY HOSTNAME PID JOBID START ELAPSED NOTES Done 5000 1 vaio 18092 tahoe.34 02/26,02:15:40 00:00:21 - Done 5001 1 vaio 18093 tahoe.34 02/26,02:15:40 00:00:21 - Done 5002 1 vaio 18100 tahoe.34 02/26,02:15:50 00:00:11 - Done 5003 1 tahoe 20478 tahoe.34 02/26,02:15:58 00:00:18 - Done 5004 1 tahoe 20483 tahoe.34 02/26,02:15:58 00:00:18 - Done 5005 1 superior 1978 tahoe.34 02/26,02:15:58 00:00:18 - *** LOGFILE: tahoe.34 jobstartcommand.log *** LOGFILE: tahoe.34 jobdonecommand.log Use '-t timeout' to control the amount of time rush waits to make a connection to each remote before it gives up. The default is 40 seconds. List Frames Examples Heading Description Stat The status of the frame. Can be any of: Que - The frame is queued, ready to be run by an available cpu Run - The frame is busy running Done - The frame completed successfully Fail - The frame failed to run successfully (exit code was 1) Hold - The frame will not run until changed manually to Que The following are transitional states for frames, which you should only see for a short time: Strt - Frame just started to run, no process id yet Die - The frame is being killed, but hasn't received an exit code back yet Frame The frame number, padded 4 digits. (Or as otherwise specified by 'framepad' in the rush.conf file.) Try The number of times this frame has been tried. Includes requeues due to exit(2), but does not include priority bumps. Hostname The name of the host that is running (or that ran) the frame. PID The process id of the render script. This is also the process group leader for the frame's process hierarchy. (In windows, the top level 'Job Object') Start The date/time the render began running. Elapsed The wall clock elapsed time in hours:minutes:seconds. Notes Free form notes text, set by the user's invocation of rush -notes, e.g. 'rush -notes 0012:"License Error"' Frames Report Format The administrator has a certain amount of control over the output format of the 'frames' report via the rush.conf file, specifically with the FrameFmt, FrameHeader1, FrameHeader2, FramePad commands.

rush -lff

rush -lff [-t timeout] [jobid..] List Frames Full. A 'full' report of all frames' state information. This report prints out more information than people usually need. This command is more intended to either be parsed by external scripts needing access to all information rush can provide, or for debugging. Use '-t timeout' to control the amount of time rush waits to make a connection to each remote before it gives up. The default is 40 seconds.

rush -lfi

rush -lfi [-t timeout] [jobid..] List Frame Information. Lists Frame info for current [specific] job, including average render times, ETAs, percent Busy/Done/Fail, etc. Example: 'rush -lfi' Report % rush -lfi vaio.139               # List Frame Info for job 'vaio.139' Average Total Jobid State Total Perc Elapsed Elapsed Average ETA ------------ ----- ----- ---- ---------- ---------- ------------------------ rotwang.3 Que 2 %4 - - - rotwang.3 Run 2 %4 - - - rotwang.3 Done 46 %92 00:00:11 00:08:36 Thu Feb 12 17:47:16 2004 rotwang.3 Fail 0 %0 - - - rotwang.3 Hold 0 %0 - - - rotwang.3 --- rotwang.3 Render Elapsed: 00:02:25 rotwang.3 Render Start: 02/12,17:44:45 rotwang.3 Render End: 02/12,17:47:10 Jobid The jobid for this job. (If multiple jobs are being listed, this column shows which info goes with which job) State The various states the frames can be in, and to the right, the accumulated data for all the frames in each of those states. Total The total number of frames in each 'State'. Perc The percentage of frames in each 'State'. Average Elapsed The average render times. This is the sum of all the Done frames' render times divided by the total Done frames. (Currently only 'Done' state frames are shown) Total Elapsed The total elapsed time for the frames; a sum of all the 'Elapsed' times in the 'Frames' report. (Currently only 'Done' state frames are shown) Average ETA This is the estimated time of completion for the job, based on the average render time for frames rendered successfully so far vs. the wall clock time spent running the job. e.g.: oldest_start = "The oldest start time for all Done frames" recent_end = "Most recent end time for all Done frames" time_spent = ( recent_end - oldest_start ) time_per_frame = time_spent / total_done_frames time_to_go = time_per_frame * ( total_que + total_hold ) This time will vary widely, since completion time is dependent on the cpu availability, which is always changing. Render Elapsed The elapsed time for rendering, ie. how long the TD had to wait for the job to finish rendering. The difference between the 'Render Start' and the 'Render End' times. Render Start The 'Start Time' for the first frame. Render End The 'End Time' for the last frame that finished rendering. Warning: the ETA is meant for ballpark estimates only, and is not meant to be taken literally. Use '-t timeout' to control the amount of time rush waits to make a connection to each remote before it gives up. The default is 40 seconds.

rush -lhc

rush -lhc [criteria] List Host Criteria. Shows all [specific] host criteria your sysadmin has configured in rush. If no arguments are specified, all host criteria are listed. Otherwise, arguments can be the criteria names to limit the report to display. Both criteria and host names are sorted alphabetically. 'rush -lhc' Reports % rush -lhc       # Lists all criteria when no arguments specified intel: vaio rotwang irix: erie ontario superior linux: rotwang tahoe vaio % rush -lhc linux       # Lists only hosts matching 'linux' criteria   linux: rotwang tahoe vaio

rush -lhg

rush -lhg [+hostgroup..] List Host Groups. Shows all [specific] hostgroups your sysadmin has configured in rush. If no arguments are specified, all hostgroups are listed. Otherwise, arguments can be the names of hostgroups to limit the report to display. Both hostgroups and hostnames are sorted alphabetically. 'rush -lhg' Reports % rush -lhg       # Lists all hostgroups when no arguments specified   +any: erie ontario rotwang superior tahoe vaio +dante: erie ontario superior +intel: rotwang tahoe vaio +irix: erie ontario superior +linux: rotwang tahoe vaio % rush -lhg +dante       # Lists only the '+dante' hostgroup +dante: erie ontario superior

rush -lj

rush -lj [-fmt str|env|defaults|help] [-x] [-t timeout] [hosts|+hostgroups..] [jobids..] List Jobs. Shows list of jobs. If '-' is specified as an argument, jobids are read from stdin. (Useful if the list of jobids exceeds operating system limits for argument lists and environment variable sizes) If one or more space-delimited [hosts..] are specified, the list of all jobs being managed by each host is shown. If one or more space-delimited [jobids..] are specified, only those jobids are listed. If neither [hosts..] or [jobids..] are specified, the contents of the RUSH_JOBID environment variable is checked for jobids, and all jobs managed by the servers of those jobids will be listed. If none of the above are available, 'rush -lj' defaults to listing all jobs being managed by the local machine. rush -lj options Option Description -x Enable 'extended' fields. A shortcut method for showing some fields users like to see besides the default plain report. The -x report format is defined by the rush.lj_x.format command. -t timeout Controls the number of seconds rush waits to make a connection to each remote host before it gives up. The default timeout is 40 seconds, eg. '-t 40', the default defined in rush.conf by the tcptimeout command. Use this if there are many machines on your network that are turned off, and you don't want to wait a full 40 seconds for each host to respond. (eg. '-t 3' will be much quicker). -fmt str Sets a custom report formatting string. Same format as the 'rush -ljf' report; see that for more info. Example: rush -lajf -fmt "Jobid Title Status" The special flag "-fmt env" lets you use define the field names in the RUSH_LAJF_FMT environment variable, to avoid having to specify the flags on the command line each time. Example: 'export RUSH_LAJF_FMT="Jobid Title"; rush -lajf -fmt env' The special flag "-fmt defaults" forces the software's built in format defaults (all fields shown). - Read jobids from stdin. This, as opposed to specifying them on the command line. Use this if the number of jobids to be specified might be more than your shell's command line limit enforces. 'rush -lj' Reports [you@erie] % rush -lj                   # List Jobs on local workstation STATUS JOBID TITLE OWNER %DONE %FAIL BUSY ELAPSED REMARKS -------- -------------- ------------------------- -------- ----- ----- ---- ---------- -------- Run erie.167 100/340/master tamu %18 %0 8 01:15:28 Run erie.169 100/410/master tamu %75 %0 20 01:11:21 Run erie.170 100/390/master tamu %10 %34 4 01:10:44 Run erie.171 100/360/master tamu %10 %34 4 01:02:43 [you@erie] % rush -lj tahoe             # List Jobs on remote host tahoe STATUS JOBID TITLE OWNER %DONE %FAIL BUSY ELAPSED REMARKS -------- -------------- ------------------------- -------- ----- ----- ---- ---------- -------- Run tahoe.5 100/540/master izzie %25 %0 4 00:30:01 Run tahoe.6 100/540/comp izzie %25 %0 4 00:30:02 Run tahoe.10 100/640/master izzie %10 %0 4 00:22:48 Pause tahoe.11 100/640/comp izzie %12 %0 4 00:22:49 Job paused. [you@erie] % rush -lj tahoe.5 tahoe.10  # List Jobs tahoe.5 and tahoe.10 only STATUS JOBID TITLE OWNER %DONE %FAIL BUSY ELAPSED REMARKS -------- -------------- ------------------------- -------- ----- ----- ---- ---------- -------- Run tahoe.5 100/540/master izzie %25 %0 4 00:30:05 Run tahoe.10 100/640/master izzie %10 %0 4 00:22:52 [-x] is an optional 'extended report' flag that includes job progress bars; 'blue' indicates frames rendering, 'green' indicates frames done successfully, 'red' indicates failed frames. These colors will appear in irush reports and terminals that support "ANSI" colors or XTERM colors. [-fmt str] is an optional flag to control the formatting of the report. You can choose which fields to show from a table of possible field names, allowing you to completely customize the report. eg: 'rush -lj -fmt' Reports % rush -lj -fmt "Jobid:-10 Status:-8 Title:-20 Progress:-20 Priority[Vals]:-5 Owner" Jobid Status Title Progress Pri Owner tahoe.1 Done SMX:DIRECTOR_V2 ____________________ 100 erco tahoe.5 Done SMX:DIRECTOR_V3 ____________________ 100 root tahoe.7 Pause SMX:HD_FIXUPS ____________________ 100 root % export RUSH_LJ_FMT='Jobid:-10 Status:-8 Title" # Another way to do the same thing.. % rush -lj -fmt env # '-fmt env' uses the RUSH_LJ_FMT variable's setting Jobid Status Title tahoe.1 Done SMX:DIRECTOR_V2 tahoe.5 Done SMX:DIRECTOR_V3 tahoe.7 Pause SMX:HD_FIXUPS A complete list of fieldnames can also be shown from the command line with 'rush -lj -fmt help'. You can also use the RUSH_LJ_FMT environment variable to pre-define a format string, and then use it at any time with just 'rush -lj -fmt env'. Finally, the systems administrator can change the default format for the report with the rush.lj.fmt command in the rush.conf file. Most all unix terminals support this feature, including xterm, konsole, rvxt, OSX "Terminal", Windows "putty". As of this writing, DOS is the only popular terminal application that does not support ANSI colors. Example: 'rush -lj -x' Report % rush -lj -x           # include extended info Status Jobid Title Owner %Done %Fail %Hold #Frms Busy Priority Ram Progress Rendertime Age Remarks -------- ---------- ------------------------- ------ ----- ----- ----- ----- ----- -------- ----- -------------------- ------------ ------------ ------- Pause tahoe.3 AE_8-009_0056_v012.aep jal %0 %0 0 100 0 10 1000 ____________________ 00:00:00 00:03:10 Job paused. Done tahoe.4 AE_8-005_0010_v010.aep jal %80 %20 0 100 0 10 1000 ____________________ 00:10:12 00:32:56 Run tahoe.5 AE_8-011_0090_v003.aep jal %70 %0 8 100 20 90 1000 ____________________ 00:15:35 00:16:51 Run tahoe.6 AE_8-011_0091_v001.aep jal %40 %0 12 100 40 90 1000 ____________________ 00:10:40 00:10:51 ↑ ↑ ↑ The default 'rush -lj' report shows the following information: Job Report Headings Heading Description Status The status of the job. Here's a state diagram showing the various states the job status transitions through: Click on the image to see a larger version. Wait - The job is waiting for another job or time to finish (WaitFor, -waitfor) Pause - The job has been paused with -pause Run - The job is available to run frames Done - The job is done, all the frames rendered successfully Fail - The job is done, some frames failed The following are transitional states for the job, which you should only see for a short time: End - the job was ended with -end Dump - the job was dumped with -dump Done - all frames Done, about to run JobDoneCommand, -jobdonecommand DoneCmd - the configured JobDoneCommand is running DumpCmd - the configured JobDumpCommand is running Remove - about to be removed from the system Jobid The job's jobid. Title The job's title (Title, -title). Owner The user that submitted the job. %Done The percentage of frames that are in the Done state. %Fail The percentage of frames that are in the Fail state. Busy The number of frames currently in the Run state. Elapsed The elapsed time in HH:MM:SS since the job started running. Progress A 20 character-wide color progress bar (using XTERM compatible ANSI codes) Remarks This field may contain messages like 'Job paused.' or 'Wait for other jobs'. The default 'rush -lj -x' report shows the following information: Job Report Headings Heading Description Status The status of the job. Here's a state diagram showing the various states the job status transitions through: Click on the image to see a larger version. Wait - The job is waiting for another job or time to finish (WaitFor, -waitfor) Pause - The job has been paused with -pause Run - The job is available to run frames Done - The job is done, all the frames rendered successfully Fail - The job is done, some frames failed The following are transitional states for the job, which you should only see for a short time: End - the job was ended with -end Dump - the job was dumped with -dump Done - all frames Done, about to run JobDoneCommand, -jobdonecommand DoneCmd - the configured JobDoneCommand is running DumpCmd - the configured JobDumpCommand is running Remove - about to be removed from the system Jobid The job's jobid. Title The job's title (Title, -title). Owner The user that submitted the job. %Done The percentage of frames that are in the Done state. %Fail The percentage of frames that are in the Fail state. %Hold The percentage of frames in the 'Hold' state. #Frms The total number of frames in the job. Busy The number of frames currently in the Run state. Priority The priority for the cpus in the job. If cpus have different priorities, they'll be listed comma separated in decreasing order. This can be shown in the -fmt report with 'Priority[Vals]:-8' Ram The amount of ram the job has requested Progress A 20 character-wide color progress bar (using XTERM compatible ANSI codes) Rendertime The wallclock time the job spent rendering Age The wallclock time since the job was submitted. This is the same as the 'Elapsed' time shown in the old 'rush -lj' reports. Remarks This field may contain messages like 'Job paused.' or 'Wait for other jobs'. Jobs Report Format The administrator has a certain amount of control over the default output format of the 'Jobs' report via the rush.conf file's rush.lj.fmt and rush.lj_x.fmt commands. See Also rush -ljf -- List jobs full (key:value pairs) rush -laj -- List all jobs rush -lajf -- List all jobs full (key:value pairs) rush -status -jobs -- Job status report

rush -ljc

rush -ljc [-c count] [-s secs] [-ss secs] [hosts|+hostgroups..] List Job Changes. Lists 'change counters' for the job. This is a low latency way to poll jobs to see if they've changed, ie. if any frames have changed state, or if the job has been changed in some way. This is useful for programs that need to show the entire queue, but don't want to constantly snapshot the entire queue even if nothing has changed. (see 'APPLICATION EXAMPLE' below) This command uses UDP to transact with the job server(s), and therefore is light load for even a busy queue. rush -ljc options Option Description -c cnt Sets the number of times to continuously update the report. Default is 1. -c 0 creates a continuous update. -s secs Sets the floating point number of seconds between polls. This is a minumum; time might actually be longer depending on retries caused by non-responsive machines. Use with -c to poll automatically at a specified interval. Default is 3.0. -r secs Sets the number of times to retry contacting the remote machine before giving up. Default is 4. -ss secs Sets the floating point number of seconds between udp acknowledges. You probably don't want to mess with this unless you're getting weird communications behavior. Default is 0.05. Application Example There are two python examples of how to use 'rush -ljc' shown in: examples/python/howto/ljc-simple-example.py -- Prints jobids of changed jobs examples/python/howto/ljc-example.py -- Prints job info of changed jobs A synopsis of how one might use it in a GUI application: 1) Run 'rush -ljf somehost' to get a full snapshot of all the jobs in 'somehost's queue, update an internal cache. 2) Run 'rush -ljc -c 0 -s 8 somehost' in the background to keep an eye on the job counters for changes. (This command will keep updating every 8 seconds forever) 3) Whenever one or more job counters detect a change, the main program can run the appropriate commands to get the new info, eg: a) A job counter changed? Use 'rush -ljf ..jobids..' b) A frame counter changed? Use 'rush -lf ..jobids..' c) A cpu counter changed? Use 'rush -lc ..jobids..' 4) Repeat step 3 as needed to keep the program up to date. Note: it is wise if such an application were 'stowed' to kill the background -ljc command until it is re-opened, so that it doesn't continue to traffic the server when no one can see the interface.

rush -ljf

rush -ljf [-fmt str|env|defaults|help] [-t timeout] [jobids..] [hosts|+hostgroups..] List Jobs Full. Lists jobs showing 'full information' about the job, where data is presented as "key:value" pairs that can be easily parsed by scripts. If one or more space-delimited [hosts..] are specified, the list of all jobs being managed by each host is shown. If one or more space-delimited [jobids..] are specified, only those jobids are listed. If neither [hosts..] or [jobids..] are specified, the contents of the RUSH_JOBID environment variable is checked for jobids, and all jobs managed by the servers of those jobids will be listed. If none of the above are available, 'rush -ljf' defaults to listing all jobs being managed by the local machine. This report prints out more information than most people usually need. The report is more intended for use by scripts needing access to as much information as rush can provide, or for debugging. Use '-t timeout' to control the amount of time rush waits to make a connection to each remote before it gives up. The default is 40 seconds. (New in rush 103.00) If -fmt is specified, its argument can be a space-separated list of keywords from the report, allowing you to limit the report to only show those fields of data. So where 'rush -ljf' will show ALL the fields, adding '-fmt "Jobid Title"' will only show the Jobid and Title fields from the report. Doing this also makes the rush communications use less bandwidth; useful if you just need a few fields from a LARGE list of jobs. 'rush -ljf' Report $ rush -ljf Jobid: tahoe.2 State: Done ActState: Done RebootId: 27 Title: HONDA DefPriority: 1 LogDir: //server/jobs/HONDA/SC4A/rushlogs LogExt: - LogFlags: - ImgCommand: xv //server/jobs/HONDA/SC4A/imgs/sc4a-%04d.tif Ram: 1 Nice: 10 MaxCpus: 0 MaxTime: 00:00:00 MaxTimeState: que LicPauseSecs: 00:01:00 LicPauseTimer: 00:00:00 FrameFlags: off Command: python //server/jobs/HONDA/SC4A/render-vehicle 640 480 ChkCommand: - JobDoneCommand: - JobStartCommand: - JobDumpCommand: - AutoDump: off WaitForState: dump WaitForTime: - User: erco (1000/1000) DoneMail: - DumpMail: - StartDate: Fri Dec 9 20:58:37 2011 EndDate: - FifoSchedOrderDate: 12/09/11,20:36:47.2 FifoSchedOrder: 1322168315195 Elapsed: 61:07:27 Frames: 2 FramesQue: 0 FramesRun: 0 FramesDone: 2 FramesFail: 0 FramesHold: 0 JobRemarks: - RushRemarks: Cpus: superior=2@100 Cpus: +farm=20@10 Notes[0]: PROD: Please see versions 1, 2 and 4 of this shot Notes[1]: ADMIN: Backup and remove at end of show Notes[2]: WRANGLERS: If this shot runs out of memory, limit the job to the +farm_bigmem hostgroup JobData[0]: COMMAND: ls -la JobData[1]: ASSETS: LINE ONE JobData[2]: ASSETS: LINE TWO JobData[3]: NOTES: requeued job JobData[4]: ASSETS: LINE THREE Criteria: $ rush -ljf -fmt 'Jobid Command Frames' Jobid: tahoe.2 Command: python //server/jobs/HONDA/SC4A/render-vehicle 640 480 Frames: 2 $ rush -ljf -notes 'Notes[0]' Notes[0]: PROD: Please see versions 1, 2 and 4 of this shot $ rush -ljf -notes 'Notes[ADMIN]' Notes[1]: ADMIN: Backup and remove at end of show $ rush -ljf -notes 'Notes[WRANGLERS]' Notes[2]: WRANGLERS: If this shot runs out of memory, limit the job to the +farm_bigmem hostgroup $ rush -ljf -fmt 'JobData' JobData[0]: COMMAND: ls -la JobData[1]: ASSETS: LINE ONE JobData[2]: ASSETS: LINE TWO JobData[3]: NOTES: requeued job JobData[4]: ASSETS: LINE THREE $ rush -ljf -fmt 'JobData[1]' JobData[1]: ASSETS: LINE ONE $ rush -ljf -fmt 'JobData[COMMAND]' JobData[0]: COMMAND: ls -la $ rush -ljf -fmt 'JobData[ASSETS]' JobData[1]: ASSETS: LINE ONE JobData[2]: ASSETS: LINE TWO JobData[4]: ASSETS: LINE THREE

rush -licpause

rush -licpause [jobid..] rush -licpause - Pause Job Into A License Pause State. Causes the current job to pause for the number of seconds specified by the submit command 'LicPauseSecs' or by the most recent 'rush -licpausesecs' command. If [jobid..] is specified, that job(s) is changed to the LicPause state. If '-' is specified, jobids are read from stdin. (Useful if the list of jobids exceeds operating system limits for argument lists and environment variable sizes) If neither [jobid..] or '-' is specified, the RUSH_JOBID environment variable is used to determine the jobid(s). Normally 'rush -licpause' is executed from within a render script when it detects the renderer failed with a license error, causing the job to pause for typically a minute or two, then unpauses itself again. For info on how to use 'rush -licpause' mechanism, see the 'How To' documentation on Render License Errors. 'rush -licpause' will be ignored if the job has already been paused with 'rush -pause'. 'rush -licpause' Example : (your render script) : ## YOUR RENDER COMMANDS HERE render /job/MYSHOW/MYSHOT/ribs/foo.rib set $err = $status if ( $err == $PRMAN_LIC_ERROR ) then # LICENSE ERROR OCCURRED -- PAUSE JOB, REQUEUE FRAME rush -licpause rush -notes ${RUSH_FRAME}:'License Error' exit 2 endif : See Also LicPauseSecs -- Submit command to set the license pause seconds rush -licpausesecs -- Command line flag to change #secs job pauses during -licpause

rush -licpausesecs

rush -licpausesecs secs [jobid..] Set Pause Time for License Errors Sets the amount of time a job remains in the 'Pause' state when 'rush -licpause' is invoked from a render script. For info on how to use 'rush -licpause' mechanism, see the 'How To' documentation on Render License Errors. See Also LicPauseSecs -- Submit command to set the license pause seconds rush -licpausesecs -- Command line flag to change #secs job pauses during -licpause rush -licpause -- Command line flag to induce job into a 'license pause' state

rush -log

rush -log [-tail] [-showpath] <framerange> [jobid..] View Frame Error Logs. Prints the frame logs for the specified frame range. The '-tail' option can be specified to continuously output appended data as the log file grows. Using the job's 'logdir' value, prints the logs found in that directory for the frames you specify, e.g.: 'rush -log' Example % rush -log 1-10,2 20   View logs for frms #1-10 on 2s, and frm #20   (New in rush 102.42a9b and up) The '-showpath' flag causes the report to show the pathname of the log file for the frame(s) specified. eg. 'rush -log -showpath' Example % rush -log -showpath 5             # show logfile pathname for frame 0005 LOGFILE: tahoe.4 /jobs/HONDA/SC13/doors-open.mb.log/0005 Irush internally makes use of the -showpath flag when it wants to show the log in a text editor. This flag will take into account any log filename extensions enabled with the rush.conf file's framelog.ext setting. So if the framelog.ext flag is set to ".txt", then you will see that extension on the pathnames, e.g.: 'rush -log -showpath' with .txt extension % rush -log -showpath 5 LOGFILE: tahoe.4 /jobs/HONDA/SC13/doors-open.mb.log/0005.txt

rush -logdir

rush -logdir pathname [jobid..] Log Directory. Changes the job's log directory, where frame log files are written to. This does not affect commands that are already running or have run. i.e., old logs are not moved to the new location, or renamed on the fly. When changing the logdir with -logdir, no checks are made to see if 'path' is a valid directory. '%s' can be used to insert the current jobid into the logdir path. Note: when the logdir is changed from the command line (rush -logdir) and has an embedded '%s', the directory is not created for you. Auto-creation of the logdir only occurs during job submission to avoid the "catch-22" scenario where the caller can't create the directory with a jobid in it if the jobid doesn't exist yet. Embedding the Jobid in the Log Directory's Path rush -logdir //server/jobs/logs/%s    This sets the LogDir to: //server/jobs/logs/tahoe.34   See LogDir for more information.

rush -logext

rush -logext -|.txt [jobid..] Log Extension. Changes the filename extension used on all the text files saved into the job's log directory. The default is normally no extension, however the sysadmin can change the network-wide default via the framelog.ext in the rush.conf file. Changing the log extension while a job is running will only affect the logs for frames that haven't started rendering yet; frames that have already rendered or are rendering will still have the old filename extension. It is for this reason it's usually better to either submit the job with the correct 'logext' command, or have the sysadmin change the network wide default in the rush.conf file. Changing Log Filename Extensions rush -logext - tahoe.55 Disables filename extensions for log files. Example: //server/some/path/logs/0001 //server/some/path/logs/0001.old //server/some/path/logs/framelist //server/some/path/logs/jobinfo rush -logext .txt tahoe.55 Causes all new frame logs to have ".txt" appended. Example: //server/some/path/logs/0001.txt //server/some/path/logs/0001.old.txt //server/some/path/logs/framelist.txt //server/some/path/logs/jobinfo.txt Caveats Changing the log extension while a job is running will not affect frames already rendered, or are in progress. Changing this setting while a job is running will affect irush(1): irush will use the new log extension setting to view all logs, effectively preventing it from seeing logs for frames rendered with the old setting. It is for these reasons it's better to set the logext either as part of the job submission, or have the sysadmin set the network wide default in the rush.conf file. See Also logext -- Submit command to set the log filename extension framelog.ext -- Rush config file command to set the network-wide default

rush -logflags

rush -logflags <-|keeplast|keepall> [jobid..] Log Flags. Changes the log flags for the job. Examples: 'rush -logflags' Examples rush -logflags - Logs are overwritten (Default) rush -logflags keepall   Keep all logs; concatenate old to *.old (e.g. 0012.old) rush -logflags keeplast    Like 'keepall', but only keeps last log (don't concatenate) See Also LogFlags -- Submit command to set the logging flags

rush -maxcpus

rush -maxcpus <#cpus> [jobid..] Sets the maximum number of cpus a job can use. Puts a cap on the entire job. If maxcpus is set to 0, there is no limit. MaxCpus rush -maxcpus 0 Disabled -- no limit rush -maxcpus 15 Limit job to no more than 15 cpus busy rendering See Also MaxCpus -- Submit command to set the maximum cpus the job can use

rush -maxtime

rush -maxtime <hh:mm:ss> [jobid..] Sets maximum time for rendering frames. Value is in HH:MM:SS (hours:minutes:seconds). The system will automatically kill frames that exceed the specified maxtime. You can control what happens to the frame when maxtime expires using MaxTimeState. See Also MaxTime -- Submit command to set the maximum time for rendering frames

rush -maxtimestate

rush -maxtimestate <que|fail|done|hold> [jobid..] What happens when MaxTime expires. By default, rush requeues (Que) a frame when its MaxTime timer expires. You can change this to any of: 'rush MaxTimeState Values rush -maxtimestate que Frames become "Que" when timer expires rush -maxtimestate fail Frames become "Fail" when timer expires rush -maxtimestate done Frames become "Done" when timer expires rush -maxtimestate hold Frames become "Hold" when timer expires

rush -nice

rush -nice <niceval> [jobid..] Set Job's Niceness. Sets the nice value for the job; 0 runs as normal user process, higher values (10, 20) increase niceness to others. See Also Nice -- Submit command to set the job's unix 'niceness'

rush -notes

rush -notes <framerange>:'notes..' [jobid..] Frame Notes. Sets Notes for frame(s) on current [specific] job. These notes will show up in the rightmost column of 'rush -lf' reports. New in 103.06 and up. This command now uses the low latency UDP protocol, and so is safer to use on a large scale than the older TCP implementation (which could 'storm' the server with high latency TCP requests if many of the commands all ran across the farm in parallel at once). In older releases of Rush (103.05 and older), it is suggested to use 'rush -exitnotes' instead if you need to set the notes from within a render script when a frame completes. Examples: 'rush -notes' Examples rush -notes 155:"license error"   set notes for frame 155 to 'license error' rush -notes 200-250:"redo" set notes for frames 200 thru 250 to "redo" Here's an example showing how to set the notes for frames 3 through 5 for a job: Setting The 'Notes' For Frames % rush -notes 3-5:"Redo For Client" [ontario.4] 0003: Redo For Client [ontario.4] 0004: Redo For Client [ontario.4] 0005: Redo For Client % rush -lf on.4 STAT FRAME TRY HOSTNAME PID JOBID START ELAPSED NOTES Done 0001 1 ontario 7762 ontario.4 02/23,16:17:26 00:00:11 Done 0002 1 ontario 7764 ontario.4 02/23,16:17:26 00:00:11 Done 0003 1 ontario 7777 ontario.4 02/23,16:17:38 00:00:12 Redo For Client Done 0004 1 ontario 7779 ontario.4 02/23,16:17:38 00:00:12 Redo For Client Done 0005 1 ontario 7787 ontario.4 02/23,16:17:51 00:00:12 Redo For Client   Latency Issues Most latency issues with running 'rush -notes' were solved in the Rush 103.06 release which changed to using the lower latency UDP protocol, allowing even large networks to adjust the notes en-masse without causing ill effects to the jobserver. In older versions of Rush (103.05 and older), 'rush -notes' used the higher latency TCP protocol, bad if for example 200 machines all ran that command at once, overburdening the jobserver daemon for that job, "storming" the jobserver's kernel with too many sustained TCP connections. The newer UDP behavior in 103.06 (and up) avoids this issue. Before that, the only option was the 'rush -exitnotes' command (added in Rush 102.42a9) which used UDP, but could only change the notes when the render script exited. (The notes change happened as part of the rush messages that deliver the render script's exit code back to the job server). This is no longer needed in 103.06, as 'rush -notes' has become safer to use with its newer UDP implementation. See Also Notes -- Submit command to set the job's notes rush -exitnotes -- Rush command line 'low latency' flag for renders to add notes to frames report

rush -offline

rush -offline [-foe] [-msg 'text'] [remotehost|+hostgroup..] Offline A Machine. Offline's the rush daemon on the specified hosts/hostgroups. If hostnames/hostgroups aren't specified, the local machine's rush daemon is taken offline. When a machine is taken offline, frames that are already rendering are allowed to complete before taking the processors offline. Once offline, no new frames will be started. [-foe] "Fail On Error". Causes the command to stop on any hostname lookup errors (such as temporary DNS or LDAP issues), instead of just printing warnings and continuing to run to handle any other hostnames specified. (default: off) *This flag new in 103.07* 'rush -offline' is similar to 'rush -getoff', differing only in that -offline allows any currently rendering frames to complete before taking the processors offline, whereas 'rush -getoff' will bump any running renders, freeing up the processors right away. The bumped frames will be requeued. An optional remark can be specified via "-msg 'text'" which will show up in 'rush -lac' reports, eg: Offline With Custom Message % rush -offline -msg 'Bad Memory' ontario ontario: Offline % rush -lac HOST OWNER JOBID TITLE FRM PRI PID ELAPSED REMARKS ---------- -------- -------------- ------------------------- ---- ----- ------- ---------- -------- ontario - - - - - - Offline Bad Memory : Examples of using 'rush -offline':  'rush -offline' Examples  rush -offline   offline all cpus on local host rush -offline tahoe offline all of tahoe's cpus rush -offline +farm   offline the entire render farm rush -offline -msg 'Failing drive' tahoe   offline 'huron' with the remark 'Failing drive' To return processors to the online state, use rush -online. Changes to the online/offline state are appended to the rushd.log. Also: (new in 102.42a9), changes to the online/offline state append 's' entries to the cpu.acct accounting log

rush -online

rush -online [-foe] [-msg 'text'] [remotehost|+hostgroup..] Online A Machine. Online's the rush daemon on the specified hosts/hostgroups. If hosts/hostgroups are not specified, the local machine's rush daemon is put online. When a machine is online, frames will immediately be allowed to start rendering on the available processors. The '-msg' flag is not recommended for use with -online, due to the message's persistence in 'rush -lac' reports when online, but is supported for symmetry with the -getoff/-offline commands. [-foe] "Fail On Error". Causes the command to stop on any hostname lookup errors (such as temporary DNS or LDAP issues), instead of just printing warnings and continuing to run to handle any other hostnames specified. (default: off) *This flag new in 103.07* Examples of using 'rush -online': 'rush -online' Examples rush -online   Online all cpus on local host rush -online tahoe Online all cpus on host tahoe rush -online +farm   Online all cpus in the '+farm' hostgroup    To take hosts offline, use either rush -offline or rush -getoff. Changes to the online/offline state are appended to the rushd.log. Also: (new in 102.42a9), changes to the online/offline state append 's' entries to the cpu.acct accounting log

rush -pathconvert

rush -pathconvert [-list] <pathname> Do pathname conversions When the admin configures pathname-to-pathname conversions in the rush/etc/path_convert file, Rush will internally use these mappings (eg. for 'logdir') Scripts can use this flag to translate pathnames into the format configured by the systems administrator in the optional The rush/etc/pathconvert file is used internally by Rush to allow the sysadmin to change e.g. the log directory, so that paths that start with "/Volumes/share" get automatically changed into the more network-compatible path "//someserver/sharename". Rush provides external scripts access to these custom mappings as well via 'rush -pathconvert [pathname]'. So with the above mapping, the command: rush -pathconvert /Volumes/share/foo ..would print on stdout the revised pathname: //someserver/sharename/foo The following example shows how 'rush -pathconvert pathname' can be used to translate pathnames from within e.g. a csh script: Sample use of 'rush -pathconvert' in a script #!/bin/csh -f # MyRender <xres> <yres> <scenefile> set xres=$1 set yres=$2 set scenefile=`rush -pathconvert $3` Render -r mr -s $RUSH_FRAME -e $RUSH_FRAME $scenefile if ( $status ) exit 1 exit 0 New in 103.03 and up. The optional "-list" flag can be specified to list all the path conversions the sysadmin has configured in the rush/etc/pathconvert file.  Using 'rush -pathconvert' -list option  $ rush -pathconvert -list FROM TO --------------- -------------------- /ourserver/data //ourserver/data /Volumes/data //ourserver/data z: //ourserver/data

rush -pause

rush -pause [jobid..] rush -pause - Pause Job Pauses the current [specific] job. Busy frames will be allowed to finish, no new frames will be started. If '-' is specified, jobids are read from stdin. (Useful if the list of jobids exceeds operating system limits for argument lists and environment variable sizes) To pause a job and kill the running frames, use:  Pause a Job, Kill Running Frames  rush -pause && rush -que run To continue a job from pause, use rush -cont.

rush -ping

rush -ping [-t timeout] [-foe] [remotehost|+hostgroup..] Ping Rush Daemon. (Administrative) Pings the local [remote] daemon to see if it's running, and what it's doing. Use '-t timeout' to control the amount of time rush waits to make a connection to each remote before it gives up. The default is 40 seconds. [-foe] "Fail On Error". Causes the command to stop on any hostname lookup errors (such as temporary DNS or LDAP issues), instead of just printing warnings and continuing to run to handle any other hostnames specified. (default: off) *This flag new in 103.07* Ping Info % rush -ping +any -t 3 ozark: RUSHD-64bit 103.00/Linux PID=1534 Boot=02/03/11,20:08:26 Online, 0 jobs, 0 procs, 0 tasks, dlog=-, nfd=7, ssb=1402, sched=rr ta: RUSHD-64bit 103.00/Linux PID=8263 Boot=01/25/11,11:25:02 Online, 2 jobs, 0 procs, 0 tasks, dlog=-, nfd=7, ssb=15419525, sched=rr tower: RUSHD-64bit 103.00/Mac PID=12233 Boot=01/15/11,15:42:14 Offline, 1 jobs, 0 procs, 0 tasks, dlog=-, nfd=8, ssb=4101073, sched=rr crystal: RUSHD-64bit 103.00/Mac PID=1861 Boot=01/19/11,01:27:41 Online, 2 jobs, 0 procs, 0 tasks, dlog=-, nfd=8, ssb=1427328, sched=rr superior: RUSHD-64bit 103.00/WinXP PID=940 Boot=02/03/11,20:29:51 Online, 0 jobs, 0 procs, 0 tasks, dlog=-, nfd=4, ssb=36790, sched=rr ----- ------ ----- --------- ---------------------- ------- ------ ------- ------- ------ ----- --------- -------- | | | | | | | | | | | | | | | | | | | | | | | | | Scheduler setting in rush.conf | | | | | | | | | | | | rr=round robin | | | | | | | | | | | | fifo=first-in,first-out | | | | | | | | | | | (debugging) | | | | | | | | | | (debugging) Number of open file descriptiors | | | | | | | | | | Used to detect leaks. | | | | | | | | | Daemon's current logging flags. | | | | | | | | | (Can be changed with 'rush -dlog xxx') | | | | | | | | Number of tasks scheduled | | | | | | | Number of procs busy running renders. | | | | | | Number of jobs being hosted by this machine. | | | | | Daemon's online/offline state. | | | | | Controlled by 'rush -online/-offline/-getoff' | | | | Daemon's start time. | | | Daemon's PID | | Operating system details. | Daemon's version number. Daemon executable (32bit=32bit application, 64bit=64bit application)

rush -push

rush -push [-s secs] [-c tries] <file[,file..]> [host|+hostgroup] Push File(s) To Remotes. (Administrative) Pushes rush configuration files (such as rush.conf, hosts, or any files in the rush/etc directory) to remote servers. Use to re-distribute one machine's rush config files to all machines quickly. -s secs - Specifies the number of seconds to wait for replies from remotes. Default is 5. -c tries - Number of retries made if no response in the number of seconds specified (-s secs). Default is only 1 try is made. Files to be 'pushed' must be specified by name. Only files in the rush/etc directory can be 'pushed'. Specify filenames only, not full paths. More than one file can be specified if separated by commas. "file" may only contain the characters "A-Z", "a-z", "0-9", "-", "_", and a single ".". This prevents abusive use of -push, since only files in $RUSH_DIR/etc are affected. Only root and the rush adminuser can use this command. The sysadmin can enable/disable 'rush -push' operations via a setting in the rush.conf file, using the AllowPush flag. 'rush -push' Examples % rush -push hosts,rush.conf,path_convert Push hosts, rush.conf and path_convert file to all hosts % rush -push rush.conf,license.dat     Push rush.conf and license.dat to all rush hosts   % rush -push rush.conf +linux     Push rush.conf to only hosts in the +linux hostgroup % rush -push rush.conf tahoe huron     Push rush.conf to hosts 'tahoe' and 'huron' only % rush -push rush.conf,hosts,license.dat tahoe huron     Push rush.conf, hosts, and license.dat to hosts 'tahoe' and 'huron' only

rush -que

rush -que <framerange|framestate..> [jobid..] Re-Queue Frames Changes frame(s) into the Que state for current [specific] job. If frames are running, they are killed and enter the 'Que' state on completion. The frames to affect can either be specified as a frame range (i.e., 1-100) or as a frame state, for which all matching frames will be affected. Examples: 'rush -que' Examples % rush -que 1-100 Que frames 1 through 100 % rush -que fail Que all frames currently Fail % rush -que fail done    Que all frames currently Fail or Done   % rush -que all Que all frames (new in 102.42)

rush -ram

rush -ram <ramval> [jobid..] Set Job's Ram Use. Sets the Ram use (in MB) for the job. See Ram submit command for more info. See Also Ram -- Submit command to set the job's estimated ram use (used for scheduling processors)

rush -ramlist

rush -ramlist [remotehost..] View the ram usage of rush jobs for localhost [remotehost] machine. Shows a report of all running rush processes on the machine, including how much ram each has requested to reserve, and a running total for the available ram left over. 'rush -ramlist' Report % rush -ramlist tahoe STATE JOBID/TITLE PRI RAMUSE NOTES Busy neverland.57,grkenttest 1 800 Busy neverland.58,pflare 1 200 ------ Total ram on tahoe: 1024 Available ram on tahoe: 24

rush -rc

rush -rc <cpuspec|tidspec|hostname> [jobid..] Remove Cpu Removes Cpu from cpu list of current [specific] job. If the cpus being removed are busy running frames, the frames are killed and re-submitted elsewhere. Cpus can be removed in one of several ways: Individually by the JOBTID number, e.g. rush -rc .32 By hostname (or host alias), e.g. rush -rc tahoe, rush -rc ta By a particular cpu specification as shown in the 'rush -lc' report, e.g., rush -rc tahoe=4@200 To remove a cpu via 'JOBTID' values (e.g., 'rush -rc .334') you must precede each value with a period. When you delete by JOBTID, you are deleting single cpus from the 'rush -lc' report. Note: this report includes the JOBTID values so you can see which values to delete. If the cpu you delete is part of a larger specification, (e.g., tahoe=4@12), then the cpu count for the spec will be modified and the cpu count in that spec will be decremented as well (e.g., tahoe=3@12) If you remove a hostname (e.g., 'rush -rc tahoe') then all cpu specifications that have that host name (e.g., tahoe=3@100) will be removed. Also, any hostgroups that expand to include that host will have that host removed from the expansion (e.g., +any=3@100, which includes tahoe). Hostname aliases can also be used to remove hosts. In previous versions, hostname aliases were not guaranteed to work for 'rush -rc'. Removing a Host % rush -lc CPUSPEC[HOST] STATE FRM PID JOBTID PRI ELAPSED NOTES howland=2@900 JobPass - - 171 900 00:00:00 No more frames howland=2@900 JobPass - - 172 900 00:00:00 No more frames +any=1@1[howland] JobPass - - 147 1 00:00:01 No more frames +any=1@1[howland] JobPass - - 148 1 00:00:00 No more frames +any=1@1[nt-1] JobPass - - 149 1 00:00:31 This is a 'neverhost' +any=1@1[nt-1] JobPass - - 150 1 00:00:31 This is a 'neverhost' +any=1@1[rotwang] JobPass - - 151 1 00:00:01 No more frames +any=1@1[rotwang] JobPass - - 152 1 00:00:01 No more frames % rush -rc howland nt-1.15 'howland=2@900': Removed nt-1.15 '+any=1@1': 2 task(s) deleted % rush -lc CPUSPEC[HOST] STATE FRM PID JOBTID PRI ELAPSED NOTES +any=1@1[nt-1] JobPass - - 149 1 00:00:37 This is a 'neverhost' +any=1@1[nt-1] JobPass - - 150 1 00:00:37 This is a 'neverhost' +any=1@1[rotwang] JobPass - - 151 1 00:00:08 No more frames +any=1@1[rotwang] JobPass - - 152 1 00:00:08 No more frames If you remove a cpu specification (e.g., 'rush -rc +any=3@100'), it must match character-for-character the entry shown in the 'rush -lc' report for the job: Removing a Hostgroup % rush -ac tahoe@100 # Add a cpu. % rush -rc tahoe@100 # Now try to remove it 'tahoe@100' no such cpu specification # FAILED: need to use spec shown in 'rush -lc' % rush -lc # Look at 'rush -lc' report CPUSPEC STATE FRM PID ELAPSED .. # More complete specification in report. tahoe=1@100 Run 0002 26747 00:00:11 .. % rush -rc tahoe=1@100 # Remove using spec shown in report 'tahoe=1@100' removed # It works

rush -reload

rush -reload <[hosts|rush.conf|pathconvert]]> [host|+hostgroup..] Reload daemon's files (rush.conf, hosts..). Forces the local [remote] daemon to reload the specified file(s). The first argument after -reload can be "hosts", "rush.conf", or "pathconvert" or comma separated combinations, eg. "hosts,rush.conf". Whenever 'hosts' is specified, the rush/etc/hosts file is reloaded by the local [remote] daemon, its IP cache flushed, and the negative cache is cleared. 'rush -reload' Examples rush -reload hosts Tells the local machine's rushd to reload its hosts file flushing its IP cache and negative cache. rush -reload hosts +any Tells all machines to reload their hosts files and flush their IP and negative caches rush -reload rush.conf +any Tells all machines to reload their rush.conf files   rush -reload pathconvert +any Tells all machines to reload their rush/etc/pathconvert files (if any)   rush -reload hosts,rush.conf +any Tells all machines to reload hosts and rush.conf and flush their IP and negative caches rush -reload hosts tahoe geneva Tells only 'tahoe' and 'geneva' to reload hosts files and flush their IP and negative caches Caveats In DNS environments, using 'rush -reload hosts +any' should be safe for your DNS server, though it will keep it steadily busy while the command is updating each host; each host will reload the hosts file, causing all the hosts to resolve to update the IP cache. If your hosts file is large, this will cause a lot of requests to your DNS server from each machine while the hosts file is reloaded and re-cached. (The exception being if your machines do their own DNS caching) Fortunately, the 'rush -reload' operates serially; it hits each machine one at a time, and waits for the remote to load the hosts file completely before moving to the next machine, ensuring there's only one machine reloading the hosts file at any given moment in time.

rush -reorder

rush -reorder <framerange..> [jobid..] Reorder Frames. Reorders frames in the frame list to the new order specified. <framerange> specifies the new order of the frames in the frame list. Several frame ranges can be specified. Unspecified frames are simply left alone. Changing the order of the framelist affects the order frames are rendered in, since frames are issued from the top of the list, down. Example-- If you have a job with 10 frames in the frame list that are in normal 1 thru 10 order, you can use 'rush -reorder' to get different orderings, such as these: 'rush -reorder' Examples rush -reorder 10-1 becomes 10 9 8 7 6 5 4 3 2 1 rush -reorder 1-10,2 2-10,2   becomes 1 3 5 7 9   2 4 6 8 10   rush -reorder 5 6 7 8 9 10 1 2 3 4   becomes exactly that order: 5 6 7 8 9 10 1 2 3 4   See Also Frames -- Submit command to set the job's frames (including custom frame# ordering)

rush -reserve

rush -reserve [-server <host>] <cpuspec> [ramval] Reserve Cpus. Reserves cpus by creating a 'dummy' job that holds the cpus. The job's title will be RESERVE. Reservation jobs are like any other-- to remove a reservation, dump the job. To change the reservation, you can use IRUSH or the usual rush commands like -ac/-rc to modify the job. 'cpuspec' indicates which processors are reserved, and at what priority. It is an error not to include a priority value in the cpuspec. The optional '-server <host>' can be specified, to make 'host' the job server for the reserve job, instead of the default which is to have the job server be on the same host as the cpus being reserved. A reservation job with a priority of '500' will prevent jobs with priorities less than 500, but yields to jobs higher than 500k. Including the 'k' flag in your reservation will also bump any renderings that are running on your machine that are lower than 500 priority. See Priority Description for more info on how rush priorities work. As an example of reserving cpus on your workstation, let's assume you sit at a dual proc workstation called 'tahoe': To reserve both processors of your dual proc workstation at a priority of '500', use:  Reserve Both Processors On A Dual Processor Workstation  rush -reserve tahoe=2@500k   Reserve both cpus at 500k priority   To submit a job that actually renders on your own workstation, such that one processor is used for rendering, leaving the other for your own interactive use, just submit with a cpu specification that requests your workstation at a priority higher than your reservation, with the 'kill' flag, e.g. "tahoe=1@510k". To get both cpus, just request both processors, e.g. "tahoe=2@510k". To remove the reservation for your machine, simply dump the reservation job. To prevent all jobs from rendering on your workstation-- even your own-- make your reservation at a priority of 999. Or, just use 'rush -offline' and/or 'rush -getoff'. The optional 'ram value' allows one to reserve an amount of ram per processor. This is useful on multiproc machines where you want to prevent large jobs from rendering on the few processors left unreserved. Increasing the ram value you reserve will decrease the size of jobs rush will allow to run on the unused processors. If 'cpuspec' doesn't include the number of processors, one processor is assumed. If 'ramval' is unspecified, a value of '1' is assumed. 'rush -reserve' Examples rush -reserve tahoe@998 Reserve 1 cpu on tahoe@998 rush -reserve tahoe=2@998 128   Reserve 2 cpus @998, 128MB of ram to each rush -reserve -server univac tahoe=2@998 128   Same as above, but jobserver will be 'univac'   rush -reserve tahoe=2@500 128 Reserve 2 cpus @500, 128MB of ram to each

rush -rf

rush -rf <framerange..> [jobid..] Remove Frames. Removes frames from the frame list of the current [specific] job. If frames are Busy at the time they are removed, they will first be killed, then scheduled for removal when confirmation arrives from the remote machine(s). 'rush -rf' Examples rush -rf 10-15 Removes 10 thru 15 from the current job rush -rf 108 110 800-899 Remove frames 108, 110, and 800-899 from the current job rush -rf -10--5 Removes negative frame range: -10 thru -5 rush -rf .1-5,.1 Removes floating point frames .1 through 5    stepping by .1 (.1, .2, .3 .. 4.9, 5.0)

rush -rn

rush -rn <hostname|+hostgroup..> [jobid..] Remove Nevercpus. Removes Nevercpus for current [specific] job. 'rush -rn' Examples rush -rn tahoe meade eagle.123    Removes 'tahoe' and 'meade' from job eagle.123's nevercpus list rush -rn +farm eagle.123 Removes all hosts in the +farm group from eagle.123's nevercpus list rush -rn +any eagle.123 Removes all hosts from job eagle.123's nevercpus list

rush -rotate

rush -rotate [rushd.log|cpu.acct] [remotehost|+hostgroup..] Rotate Rush Log Files (Administrative) Rotates the rushd.log file by default on local [remote] host. The cpu.acct log can also be rotated if the optional argument 'cpu.acct' is specified. Can be used in crontab scripts to rotate logs on local or remote machines. The rushd.log is normally automatically rotated with the LogRotateHour command in the rush.conf file, however that can be disabled so that you can configure your own weekly or monthly log rotations via a crontab using 'rush -rotate'. 'rush -status' Examples rush -rotate rushd.log Rotates the rushd.log on local machine rush -rotate rushd.log tahoe ontario    Rotates rushd.log on remote hosts 'tahoe' and 'ontario' rush -rotate rushd.log +any Rotates rushd.log on all machines rush -rotate cpu.acct Rotates cpu.acct log on local machine rush -rotate cpu.acct tahoe ontario    Rotates cpu.acct log on remotes 'tahoe' and 'ontario' rush -rotate cpu.acct +any Rotates cpu.acct on all machines Only root and the rush administrators can use this command.

rush -showconf

rush -showconf [remotehost|+hostgroup..] Show Daemon's rush.conf Settings Views a remote daemon's current loaded rush.conf settings, so one can see what settings the daemon is actually using. This does not necessarily reflect the contents of the remote machine's rush.conf file, but rather, the config the daemon currently has loaded into memory. So for instance, if the rush.conf file was recently changed, 'rush -showconf' won't show the change until the daemon notices the changed rush.conf file and reloads it. (Usually within 30 seconds). Use this to verify changes to the rush.conf file were interpreted by the daemon as you expected.

rush -status

rush -status [-jobs] [-cpus] [-usage] [-s secs] [-c count] [-foe] [remotehost|+hostgroup..] Status of Host. (Administrative) 'rush -status' quickly reports the status of jobs and cpus on either the local machine, or the specified remote [host]. Commonly used as 'rush -status' to get the status of the local host, or 'rush -status +any' for the status of all hosts. If none of the options '-jobs', '-cpus' or '-usage' are specified, all are assumed. ie. 'rush -status' is the same as 'rush -status -jobs -cpus -usage'. Output is intended for other programs to parse and regenerate. 'rush -status' Options -jobs Shows job info ('j' entries). -cpus Shows cpu info ('p' entries). -usage Shows usage of cpu, memory and swap ('C', 'M' and 'S' entries). -s <secs>   Sets the amount of time to wait for responses from remotes.   Default is 3. -c <count> Sets the number of times to continuously update the report. Default is 1. -c 0 creates a continuous update. -foe "Fail On Error". Causes the command to stop on hostname errors instead of continue to run for any other hostnames that resolve correctly. (default: off) *This flag new in 103.07* The output contains several records of information for each host, one record per line. Host records start with an 'h' record, and terminate with a line of '--'. 8 different types of data records are possible. Data record types are defined by the first character in each record line, and can be one of: Line Prefixes Prefix Description h Hostname header. Leads off records for the specified host. d Daemon information. Info about the running daemon. j Job information. One line per job. (-jobs) p Processor status. One line per processor. (-cpus) C Cpu status. (-usage) M Memory status. (-usage) N Network I/O (-usage) S Swap status. (-usage) X Error message (eg. "X PdhGetFormatted[usr0]: query not validated") Each record has its own fields: h <hostname> d <sequence-id> <daemon> <version> <PID=pid> <online state> <jobs> <busy procs> <total procs> j <owner> <jobid> <job title> <job state> <elapsed> <percent done> <percent fail> <# frms busy> <"job remarks"> p <owner> <jobid> <job title> <frame> <priority> <pid> <elapsed> C <ncpus> <usr%> <sys%> [<usr%> <sys%> ..] M <total mb> <used%> S <total mb> <used%> <swapin> <swapout> <'bad'swapping> N <timeofday (in floating secs)> <in(kbytes)> <out(kbytes)> <ifaces total errs> <ifaces total spd (Mbits/sec)> X <Error message text..> W <Warning message text..> CAVEATS: 'S' (Swap) entries: o swapin and swapout and 'bad swapping' values are in 'pages' 'X' (Error) entries: o Error lines are not present unless there were fatal errors o There may be more than one 'X' line, a separate error message in each o 'X' lines should be shown to the user along with the hostname from the 'h' line 'W' (Warning) entries: o Warning lines are not present if there are no warnings o 'W' lines should be shown to the user along with the hostname from the 'h' line 'N' (Network) entries: o It is advised you graph these values as follows: { // Determine floating point #secs between last sample and current static double peak = 0; // Make sure none of the values 'wrapped' // If they did, skip calculations and just save the current as last // so that the /next/ sample will be with unwrapped values.. if ( curr_secs > last_secs && curr_in_kb > last_in_kb && curr_out_kb > last_out_kb ) { double secs_diff = curr_secs - last_secs; if ( secs_diff > 0 ) { in_diff_kbps = (curr_in_kb - last_in_kb) / secs_diff; // determine input kb per sec out_diff_kbps = (curr_out_kb - last_out_kb) / secs_diff; // determine output kb per sec io_diff_kbps = indiff_kbps + outdiff_kbps; // determine total kb per sec if ( io_diff_kbps > peak ) peak = io_diff_kbps; // determine peak kb per sec if ( peak_kbs != 0 ) { in_percent = (in_diff_kbps / peak_kbps) * 100; // percent of peak for in out_percent = (out_diff_kbps / peak_kbps) * 100; // percent of peak for out } ..graph 'in_percent' and 'out_percent'.. } } // Save current samples as 'last' last_secs = curr_secs; last_in_kb = curr_in_kb; last_out_kb = curr_out_kb; } o Any of the sample values (including the time) may wrap around. If so, it's suggested you save all the values in this sample as 'last', and skip graphing this sample. o 'timeofday' is the sample time as a floating point number of seconds It's used by the client to calculate peak kbs/sec between samples. o 'iface speed' is considered 'optional data', as it's not always provided by the OS. It's therefore recommended you not try to use the iface speed value at all, and instead calculate 'peak use' and graph against that. o To calculate peak use in kbps (kilobytes per sec), take diff between last+current in/out kbytes sample, and divide by the diff between last+current timevals. o in/out totals are totals of /all/ interfaces found. This may include 'logical' interfaces (such as filters and bridges) which may mirror a physical interface's usage. We try to ignore logical interfaces, but sometimes the OS doesn't make this evident, and in such cases we just sum them all. Thus, kb totals may be artificially scaled by 2x or 3x. 'rush -status' Examples rush -status Shows the status of the local host rush -status +any Shows the status of all hosts rush -status -usage +any Shows only the cpu usage of all hosts rush -status -jobs +any Shows only the job info for all hosts rush -status -jobs -cpus +any Shows only the job and cpu info for all hosts rush -status -jobs -cpus -usage +any   Same as 'rush -status +any'

rush -submit

rush -submit [remotehost] [-sh|-csh|-dos|-python|-perl|-jobid] Submit Job Submits a job to be managed by the local [remote] job server. Reads stdin for Rush Submit Commands which define the job submission. Optional [remotehost] can be specified to specify some other machine to be the server for the submitted job. By default, the machine that 'rush -submit' runs on becomes the machine that manages this job. This is usually the user's workstation. This ensures there's no "single point of failure" for the render queue, and distributes the overall load of managing jobs to multiple machines. Optional shell flags [-sh|-csh|-dos|-python|-perl|-jobid] control how the jobid of a successfully submitted job is printed on stdout. For instance, '-csh' allows a csh script to directly 'eval' the output of the 'rush -submit' command to automatically set the RUSH_JOBID environment variable on a successful submit, eg:  CSH using 'eval' to set the RUSH_JOBID  #!/bin/csh -f eval `rush -submit -csh` << EOF frames 1-10 command sleep 50 cpus +any=5 EOF if ( "$RUSH_JOBID" == "" ) then echo Job failed to submit exit 1 else echo Job submitted: $RUSH_JOBID rush -lj # RUSH_JOBID set by 'eval' command above rush -lf # RUSH_JOBID set by 'eval' command above endif Optional Submit Shell Flags New in 103.00 rush -submit -sh Bourne Shell syntax: RUSH_JOBID=xxx.123; export RUSH_JOBID rush -submit -csh CSH syntax: setenv RUSH_JOBID xxx.123 rush -submit -dos DOS syntax: set RUSH_JOBID=xxx.123 rush -submit -python    Python syntax: os.environ["RUSH_JOBID"]="xxx.123" rush -submit -perl Perl syntax: $ENV{"RUSH_JOBID"}="xxx.123"; rush -submit -jobid Just print the jobid: xxx.123 For examples of how to make custom scripts that use 'rush -submit', see submit scripts in various languages and the rush command line tutorial which shows how to submit and manage jobs from the command line. Simple Example % rush -submit << EOF title MY_JOB ram 1 frames 1-10 logdir //path/to/an/empty/directory command echo This is a test cpus +any=5@1 EOF When this command completes successfully, it returns an exit code of 0, and the jobid of the submitted job is printed on stdout, which can be used to monitor the job. Warnings may also be printed. If the job failed to submit, a non-zero exit code is returned, and the reason for the failure will be printed on stderr. If you're writing a GUI application that submits jobs, you should keep stdout AND stderr of the 'rush -submit' command, and present the output to the user in case of error or warnings. Here's a python example: Python Example: How to parse errors from 'rush -submit' import os,re,string # Temp file for output tmpfile = "/tmp/.rush-submit-" + str(os.getpid()) # Submit the job, save stdout+err to 'tmpfile' submit = os.popen("rush -submit > " + tmpfile + " 2>&1", 'w') submit.write("title MYJOB\n" + "frames 1-10\n" + "command ls\n" + "cpus +any=5@1\n") submit.close() # Read all lines of stdout/err from 'rush -submit' f = open(tmpfile, 'r') submitout = string.join(f.readlines()) f.close() os.remove(tmpfile) # remove tmp file # Parse jobid (if any) try: jobid = re.search("RUSH_JOBID.(\S+)",submitout).groups()[0]       except: jobid = "" # If no jobid found, submit failed if ( jobid == "" ): ShowDialogToUser("SUBMIT FAILED\n" + submitout) sys.exit(1) else: ShowDialogToUser("SUBMIT WORKED: JOBID IS " + jobid)
